1ASTS02208-2005-09 Subaru Outback Front Passenger Side Strut & Spring Assembly

Replaces

2005-09 Subaru Outback Front Passenger Side Strut & Spring Assembly TRQ SCA57985

1ASTS02208

Part Details

This part replaces:

  • Monroe 272565
  • KYB SR4491
FREE SAME DAY SHIPPING
Save 26%
List: $151.95 Save: $39.00
Part 1ASTS02208
In Stock


Orders must be placed by 2pm ET
Delivery options for:

Estimated Arrival Cost


Deliveries made to PO Boxes and FPO may take longer. See our Shipping & Delivery for more information.

TRQ
Brand #: SCA57985

Frequently bought together

Description
Vehicle Fit
Warranty & Shipping
How-To & Tools
Q&A

In the past, replacing struts required specialized tools to compress, remove and transfer the old spring and mount.  Pre-assembled with all new parts, our complete strut and spring assemblies make this job much quicker and easier for the do-it-yourself mechanic.

Each complete strut & spring assembly contains:

  • Upper Strut Mount
  • Strut Bearing
  • Coil Spring
  • Boot & Bumper Kit
  • Gas-charged Strut

To ensure the vehicle performs safely and as designed, we recommend replacing shocks & struts in pairs. If the damping rates are significantly different from side to side (like using different brand parts or mixing old with new) the vehicle body and wheel movement variations could cause handling irregularities. We also recommend performing an alignment after replacement. This will ensure proper tracking and protect your vehicle's tires from premature wear.

Pre-Assembled

Loaded strut & spring assemblies allow for a quicker, safer install than bare struts.  No spring compressor required!

Trouble-Free Install

Includes the matched parts needed. New components over reused parts provide a better ride and save you from having to repair again.

Item Condition: New

Attention California Customers:

WARNING:  This product can expose you to chemicals including Chromium (Hexavalent Compounds), which is known to the State of California to cause cancer, and birth defects or other reproductive harm.  For more information, go to www.P65Warnings.ca.gov.

Lifetime Warranty

This item is backed by our limited lifetime warranty. In the event this item should fail due to manufacturing defects during intended use, we will replace the part free of charge. This warranty covers the cost of the part only.

    A professional alignment is recommended after this repair has been completed

  1. step : Removing the Wheel (0:26)
    • Find level ground
    • Loosen the lug nuts with the vehicle on the ground with a 19mm socket and breaker bar
    • Raise the vehicle with a floor jack from the jacking point behind the oil pan (do not jack up from directly underneath the oil pan)
    • Secure the vehicle on jack stands by placing the jack underneath the pinch weld and locking the jack
    • Remove the lug nuts
    • Pull off the wheel
    • Place the wheel underneath the side frame rail
  2. step : Removing the Strut (3:21)
    • Open the hood
    • Press the tabs and remove 12mm bolt and the ABS wire bracket from the strut
    • Remove the bolt on the brake line bracket with a 12mm wrench
    • Loosen the strut nuts with a 19mm socket and a breaker bar
    • Remove one bolt
    • Remove the three nuts from the top of the strut with a 12mm socket
    • Remove the bolt from the bottom of the strut
    • Lower the strut down and out
  3. step : Installing the Strut (10:19)
    • Transfer the bolts from the old strut to the new strut
    • Insert the strut up into place
    • Line up the bolt holes with the knuckle
    • Thread a nut on top by hand
    • Insert two lower strut bolts by hand
    • Tighten the three nuts evenly to the top of the strut with a 13mm deep socket and ratchet
    • Tighten the lower bolts with a 17mm socket and ratchet
    • Torque the bolts to 112 foot-pounds
    • Insert the brake line in place and tighten the 12mm bolt
    • Tighten the 12mm bolt to the ABS wire
  4. step : Reattaching the Wheel (16:04)
    • Slide the wheel into place
    • Start the lug nuts by hand
    • Tighten the lug nuts preliminarily
    • Raise the jack
    • Remove the jack stands
    • Lower the vehicle to the ground
    • Tighten the lug nuts to 89 foot-pounds in a crossing or star pattern

Tools needed for replacement:

    General Tools

  • Jack Stands
  • Floor Jack

  • Materials, Fluids, and Supplies

  • Gloves
  • Rust Penetrant

  • Ratchets & Related

  • Socket Extensions
  • Torque Wrench
  • Ratchet

  • Screwdrivers & Related

  • Pry Bar

  • Wrenches - Metric

  • 19mm Wrench

Need help? Ask one of our Auto Experts
Need help? Ask one of our Auto Experts
Customer Q&A
Ask a question to 1A Auto customers who purchased the product
No questions have been asked about this item.

Fits the following Makes:

Year Make Model Description
2005-2009Subaru Outback Subaru Outback Front Passenger Side Strut & Spring Assembly

Part Interchange

Brand Label Part Number
KYB SR4491
KYB Shocks & Struts SR4491
Monroe 272565
Monroe Shocks & Struts 272565
Unity Automotive 11906

This item may be interchangeable with parts from other brands with the above part numbers. This information is provided only for reference and does not guarantee that the item you are purchasing is identical to parts with part numbers from the brands listed above. To confirm that this item fits your vehicle, use the above "Check Vehicle Fit" option.
