TRQ side mirrors and mirror components are designed to match the function, fixture, and performance of the original version for easy installation. TRQ mirrors are DOT certified, comply with all federal safety standards, and are independently lab tested to ensure our products comply with all government regulations. All products are fit and road-tested in our Massachusetts R&D facility to ensure we deliver on our promise of Trusted Reliable Quality.
Product Features
Direct Bolt-on Replacement: No modifications or special tools required
Complete Assembly: includes same mirror glass, housing, bracket and technology as the original unit
DOT Certified: Built to the highest quality standards
FMVSS-111 Compliant: Validated to be a dealership alternative
Exact fit - To obtain proper fit and function confirm your vehicle has the exact mirror options listed.
Paint To Match Note:
"Paint-to-match finish" refers to a smooth, paintable surface. This item is not painted. Paint offers better coverage and adhesion, but it is not necessary for installation.
Item Condition:New
Attention California Customers:
WARNING: This product can expose you to chemicals including Chromium (Hexavalent Compounds), which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov
Lifetime Warranty
This item is backed by our limited lifetime warranty. In the event that this item should fail due to manufacturing defects during intended use, we will replace the part free of charge. This warranty covers the cost of the part only.
FREE Shipping is standard on Orders shipped to the lower 48 States (Contiguous United States). Standard shipping charges apply to Hawaii, Alaska and US Territories. Shipping is not available to Canada.
Expedited is available on checkout to the United States, excluding Alaska, Hawaii and US Territories as well as P.O. Boxes and APO/FPO/DPO addresses. Final shipping costs are available at checkout.
How To Replace Side View Mirror 2004-08 Chrysler Pacifica
Created on:
Tools used
Socket Extensions
Flat Blade Screwdriver
Phillips Head Screwdriver
Putty Knife
10mm Socket
Door Panel Removal Tool
Ratchet
1. Removing the Door Panel
Pry out the trap doors behind the door handle and the pull handle.
Remove the two Phillips screws.
Using a clip tool or putty knife pry out the clips around the inside of the door panel.
Pull the door panel out, up and off.
Disconnect the harnesses by pushing up on the tabs on the bottom of each of them.
Pull the cables out and disconnect.
2. Removing the Side Mirror
Disconnect the mirror harness.
Pry out the triangular panel at the top of the door panel.
Remove the pad.
Remove the three 10mm nuts.
Pull the mirror out and off.
3. Replacing the Side Mirror
Run the harness down through the door.
Line up the mirror and push it into place.
Replace the three 10mm nuts.
Replace the pad.
Reconnect the harness.
Replace the triangular panel.
4. Replacing the Door Panel
Reconnect the cables and harnesses to the door panel.
Put the door panel up and on to the window sill.
Line up the clips and hit them in around the door panel.
Replace the two Phillips screws.
Replace the two trap doors.
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the internet.
Hi, I'm Mike from 1A Auto. I hope this how to video helps you out and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace a side rear view mirror on this Chrysler Pacifica. We show you the driver's side in the video. The passenger's side is basically the same procedure. The tools you'll need are a flat-blade screwdriver, Phillips screwdriver, a door panel clip tool or a putty knife would work, and either a 10mm wrench or a 10mm socket with a ratchet.
First, you'll take a flat blade screwdriver and there's a little trapdoor right there. You pry that forward and out, and there's one down here, you pry this one back and then out. This one, forward and off. This one, pry backwards, a little twist of the screwdriver and pull it out. Then right in behind, there's two Phillips screws, we'll remove those.
Now, a door panel clip tool and another screwdriver. The clip tool in behind here, go down to this. You'll feel this clip, take it out and get right on that clip. It came apart pretty easy. Go right around the door and release the clips right around, it's usually probably five or six clips, then pull it out and up and off.
It's a little hard to film, but start with this speaker wire. You should be able to pull it right off. Then these harnesses, they just all have little tabs right on the bottom of them, just pull up with your finger and release. Actually that middle doesn't need to be unplugged. This cable here, pull it out and pull it out and then the cable comes out and you can disconnect. There's a clip here, pull the clip off, and pull that cable up and out. This cable should pull out. It looks like this has been apart before, like somebody broke it, so there's now a wire tie holding it. Snip the wire tie. This cable, it should just snap right out of there and then it pulls forward and out. Then, finally way down is your courtesy light, same thing, it just pulls right off.
You can see your mirror plugs in right here, push down on the tab and unplug that. This carefully, pull it right out. Pull it out and then up. You don't want to pull it off too far. Take this pad and move it. Again, there's three 10mm bolts here. We're using a socket with a ratchet extension. A 10mm wrench would work just as well too. Speed up here as I just remove those three nuts that hold the mirror on. Once those are off, reach out and pull your mirror or what's left of your mirror right off.
Here's our original mirror. New mirror from 1A Auto. See, it's exactly the same. Has the same connector and everything. It's going to go on there just like the original. Let's just reverse the procedure. Put your harness through. You can use your original 10mm nuts. Again, I'll just fast-forward. I put the nuts on by hand at first and then tighten them up nice and snug. Tighten them up firmly. Don't over-tighten them. Nice and snug with your socket and ratchet or wrench.
Put this insulation back on, slide it down and in. Reconnect the mirror and push this back up in place. Slide it down there first. Make sure it goes on the other side of the metal, into place. Bring the door panel over. We're going to plug in out light way down here first, probably can't see it. Plug in our speaker. Plug in our two harnesses there. This goes in. You have to peek down around, pull your lock up. You slide it backwards in and then just leave it there for now. This one goes into the handle and lock this clip on. Bring it around, pull it back, cable in and down. As you bring the door panel towards the door, you put this cable in. Panel up and on. Peek back in here. Put our two screws back in. Put our little trim doors back on.
We hope this helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll free: (888) 844-3393. We're the company that's here for you on the Internet and in person.
MRA05665
In Stock
Product Reviews
Loading reviews
5.00/ 5.04
4 reviews
5 Stars
4 Stars
3 Stars
2 Stars
1 Star
4
0
0
0
0
Good business
Andrey
February 1, 2018
Keep up good work. Second time using your service.
Easy install; works perfect
J
January 10, 2019
This worked great on the specified vehicle. Easy installation and looks like it was always there. If we need one for the other side; will be buying that from here also.
04 Pacifica
J
September 14, 2019
Yet again great products and videos keep up the good work.
Perfect fit
Wayne
September 8, 2020
Perfect Fit delivered in 2 days Thank You
Customer Q&A
Is this mirror auto-dimming as well?January 29, 2016
Marshall L
10
No, they are not auto-dimming but they are heated
January 29, 2016
Mark W
10
No Unfortunately sorry...
January 29, 2016
Jacques L
10
Hello, No these are power glass and heated only.
February 2, 2016
Brian F
Can i replace just the glass in 2004 pacifica driver side mirror? It has discolored but still works perfectlyDecember 28, 2018
D P
10
Yes, just the glass can be replaced on your existing mirror assembly. We advise you order mirrors with the exact same options as your original, as the glass will not function properly if your vehicle does not have the same capabilities. Our mirrors are intended to be a direct plug and play replacement for the exact options listed.
December 28, 2018
Jessica D
10
I had the same issue but I opted to buy the full unit since a glass shop didnt recommend it.
December 29, 2018
