Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the idler pulley on this 2004 Chrysler Sebring with the 2.7 liter V6 engine. The items you'll need are a new idler pulley from 1AAuto.com, jack and jack stands, 13 millimeter and 19 millimeter sockets and ratchet, a 1/2 inch ratchet, a T50 torx bit, and a torque wrench.
To start off, you'll want to remove your wheel. You just want to remove the 19 millimeter lug nuts. You want to loosen them while they're on the ground, raise the vehicle and then remove them the rest of the way, unless you have air powered tools. Then, you can do the entire process up in the air.
With the wheel off, you can see the entire serpentine belt, and you just want to loosen up this bolt at the top of your tensioner. We'll just fast forward as Don does this. Now, you want to just loosen the lower bolt here on the tensioner. As he loosens it, you'll see the tensioner go slack. Now, you can pull your serpentine belt off the pulleys.
Now, you can remove those two bolts you loosened up earlier in the tensioner. Then, the tensioner comes right off. Use a flat blade screwdriver to pry off that cap. We're going to fast forward as he removes this T50 bolt. Once that bolt is removed, your idler pulley will pull right off the tensioner.
You can see the old idler pulley on the left and the new one from 1A Auto on the right. They do look a little different, but they'll work and mount exactly the same. Take your new idler pulley, push it into place and replace that T50 torx bolt. Now put your tensioner back up into place and hand tighten the two bolts in the tensioner. You don't want to over tighten them yet, because you still have to put your serpentine belt back on.
As a reference point, we're going to give you a belt diagram that's from the front of the vehicle. This is for the six cylinder. You can reference it on how to put the belt back onto the pulleys. You can also see pretty clearly in this shot how the belt goes back on. The only thing you can't see is the alternator, but you would want the ribbed side going over that. Using your half inch ratchet, you want to pull that tensioner down and then tighten those bolts up. We'll fast forward as Don tightens those the rest of the way. We'll continue to fast forward as Don replaces the wheel. You want to replace your lug nuts while it's still jacked up. Lower the vehicle and tighten them the rest of the way. Then, you want to use your torque wrench and tighten them to one hundred foot-pounds.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
