Part Details
Handle is the original color shade.
Pro Tip: Replace Handles in pairs or sets. Fading from the sun or age can make your Vehicle Handles and Bezels appear a hue difference next to new Handles.
Item Condition:
New
Attention California Customers:
WARNING: This product can expose you to chemicals including Lead and Lead Compounds, which are known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Lifetime Warranty
This item is backed by our limited lifetime warranty. In the event that this item should fail due to manufacturing defects during intended use, we will replace the part free of charge. This warranty covers the cost of the part only.
FREE Shipping is standard on Orders shipped to the lower 48 States (Contiguous United States). Standard shipping charges apply to Hawaii, Alaska and US Territories. Shipping is not available to Canada.
Expedited is available on checkout to the United States, excluding Alaska, Hawaii and US Territories as well as P.O. Boxes and APO/FPO/DPO addresses. Final shipping costs are available at checkout.
Created on:
Tools used
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike Green. I'm one of the owners of 1A Auto. I want to help you save time and money repairing or maintaining your vehicle. I'm going to use my 20-plus years experience restoring and repairing cars and trucks like this to show you the correct way to install parts from 1AAuto.com. The right parts installed correctly: that's going to save you time and money. Thank you and enjoy the video.
In this video we're going to show you how to remove and replace an inside door handle on this '97 Expedition, same as any 97-03 F150 and 97-02 Expedition. The tools you'll need are a regular screwdriver, Phillips screwdriver, and an 8mm or 5/16 socket and ratchet or wrench.
To remove the door panel is fairly simple. You need to remove some panels and then a couple screws. OK, I'm using a rag just to protect the paint to make sure I don't scratch and also protect the vinyl. First, up here, pull out on this little triangle and then you pull up. You can see it has two pins on the back and then a pin there. Then, again, with the rag pry up on your switch panel. Then on the switch panel, you can see all these connectors. They have a little tab here. You push on the tab and then pull. You just kind of have to work them. Then do the last one. Then the next thing is, you actually do want to take this mirror switch and you have to be careful without the rag. I'll just pry it up. It comes out and, again, there's a little tab here. Then the last part is right down here. On this light, insert your screwdriver. Actually you don't really need the rag. Put your screwdriver right here and pry the cover off. Once those panels are off there are two Phillips screws, one here and then one down here in the light right there. I'm going to remove those. The last thing you need to do is remove this little grommet around the door panel and you can just insert your screwdriver in here, pry it out a little bit, and then it comes off and around the handle. Once that's done, then, you just take the whole panel and lift up. The only thing you have to worry about is, back in here, there's a little light. You just twist and pull it out. Now your door panel is free from the vehicle.
Now you have the door panel off. With your inside door handle, most often, what happens is this big black plastic handle break. Pretty simply, this is an 8mm or a 5/16 if you're using standard sockets, and you just remove the bolt and the handle comes off. You can replace that. Now if it is your mechanism that's bad you can use your socket to press in the teeth here. That comes off and you'll probably need a wrench or a socket with a ratchet. Once that's off then the handle slides forward and comes off.
Then, obviously, to get it back on you would slide it in, put in your 8-mm, 5/16 bolt, and tighten up the bolt. Put your lock rod back in, and then your handle back on. Make sure everything works good.
Now you put your door panel back on and you're all set. Here in the interest of time we're just going to speed through putting the door panel back on. If you want to see this is a real time you can check out our other videos for the Expedition and F150 door panel, but you can probably pick up enough to get the door panel back on. Plus, once you take one off, getting it on is pretty much just a reverse of the procedure. There you go and we hope this helps you out
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
