TRQ drivetrain kits are manufactured using premium raw materials to restore original performance. Each TRQ drivetrain component is designed to be a direct, maintenance-free replacement to the stock unit. To extend the service life of your drivetrain, TRQ recommends replacing wheel hubs, bearings, and constant velocity (CV) drive axles at the same time to ensure even wear of components and improved ride comfort. All products are fit and road-tested in our Massachusetts R&D facility to ensure we deliver on our promise of Trusted Reliable Quality.
Install Tip: When replacing steering components, have a professional alignment performed afterwards. This ensures proper tracking and even tire wear.
Our steering and suspension components are pre-greased and sealed for long life and do not require the extra maintenance typically required by greaseable versions.
Item Condition:
New
Attention California Customers:
WARNING: This product can expose you to chemicals including Lead and Lead Compounds, which are known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Lifetime Warranty
This item is backed by our limited lifetime warranty. In the event that this item should fail due to manufacturing defects during intended use, we will replace the part free of charge. This warranty covers the cost of the part only.
Created on:
Tools used
Tools used
Tools used
Okay, friends, one of the first things we're going to talk about in this video is safety, hands and eyes. With that said, let's go ahead and safely raise and support the vehicle. And now, we're going to remove all six of our lug nuts and take the wheel off.
Now that we have the wheel off, we have a clear view of our ABS wire right here. I always like to disconnect it. We'll go ahead and pull it off of the frame right there where it's on and if you look at it, you're going to see a red tab. Push that red tab so it's away from the little indicator here. Now we're going to squeeze on this tab and separate the two. Let's continue on by removing it from the rest right along here. There's another one down here. Perfect. Set it aside. Now, looking from the backside, you're going to see two caliper bracket mounting bolts. Go ahead and remove the pair of them, and then we're going to set the whole caliper up on top of the control arm so it's safe.
Looking at the front of your rotor, you're going to see this little Torx head screw right there. Go ahead and remove that and then remove the rotor. Use your 36-millimeter socket, remove your axle nut. There we are. Give your axle a nice push. If it doesn't move inside the bearing, you need to continue on with a little punch in the center with a hammer bonk, bonk, bonk until it's free. Let's remove our outer tie rod end nut. Now, looking at the backside of the knuckle right along where the axle is, you're going to see three mounting bolts that hold the bearing to the knuckle. Go ahead and remove all three.
There it is. Go ahead and wiggle that bearing. All right, ours feels like it's ready to come off. If it doesn't for you, you can go ahead and give a bonk right along the top here, maybe along the bottom, just try to break it free. There we are. Let's go ahead and grab that backing plate off of there. There's our bearing, friends. Now, let's continue on with a nice collection bucket on the floor. We're going to spray down this area, get out any of the debris that's in there.
Okay, this looks great. You also want to make sure that this area along here is nice and clean as well, that's where the backing plate's going to ride. And then, of course, double-check that backing plate itself and make sure that that's in good condition as well. If you have any rot build-up in areas that it's supposed to make contact points, obviously you're going to have an issue. Now, let's use a little bit of copper never-seize, we're going to go along the inner portion of the knuckle right there and then, of course, this area where the mounting area is. There we are. All up along there. Beautiful. I like to put a little bit along the splines of the axle itself as well, but you definitely don't need to go on the threaded area. Now it's going to be time to clean up the threads on all of your bolts. You want to make sure there's no rust or any remaining thread locker. Once you have them cleaned, let's put on a tiny bit of thread locker ourselves.
All right, so I cleaned up my bolts, I've got some thread locker on them, I've got my backing plate, and I've got my brand new bearing. Go ahead and put the wire through your backing plate and then line up the slot right along there. You're going to notice the cutout area on one side of your backing plate, that's going to be where the caliper is supposed to be. Let's go ahead and put this bearing on there. Now, of course, we'll start all three of our bolts from the backside, we'll snug them up, and then we'll torque them to manufacturer specifications.
Now let's torque all these bolts to 133 foot-pounds. Now if you have an existing rotor that looks a lot like this, you want to make sure that you clean up this surface where the hub's going to ride. If you have some copper never-seize, go ahead and coat the area where the rotor's going to ride and, of course, make sure you get inside that bolt hole where the security bolt is. Now it's going to be time to get our rotor up on here. Make sure you line up your mounting hole and, of course, start that bolt in there and snug it up. Now, let's go ahead and get our caliper on there. I've got my two bolts with a little bit of thread locker on it. Start them both in, snug them up, and we'll torque them to manufacturer specifications. Let's torque these 170 foot-pounds. Connect in your ABS wire, click it in, give it a tug, make sure it's locked. Perfect. Go ahead and start it into the frame. Make sure everything's secure.
Let's get the tie rod nut back on here. Let's torque this to 26 foot-pounds. Tiny bit of thread locker on your axle stud there, washer, start the nut on, we're going to bottom it out carefully, and then we'll torque it to manufacturer specs as well. To torque this, the easiest way to do it would be to grab your wheel, come from the backside and you're going to bonk out this center cover right here. Now we're going to put the wheel on there and then we'll, of course, torque everything down at the same time. Now that we have the wheel touching the ground, we can torque our axle nut to 188 foot-pounds. Torque your lug nuts to 140 foot-pounds. Let's go ahead and get our cover on there. Torqued.
Okay, friends, so that was easy. Next thing you need to do is go ahead and pump up the brake and then take it for a road test. Listen for any noises and, of course, pay attention to make sure you don't have any ABS light.
Tools used
Tools used
Tools used
Tools used
One of the first things we need to do is safely raise and support the vehicle, so the wheel is off the ground. Let's remove our 22-millimeter lug nuts. Remove your wheel.
Now that the wheel's off of here, we have a clear view of the sway bar link. What you're going to notice is, up along the top, it has a strange-looking nut. It's very thin. It's going to be hard to grab onto. I'm going to use a pair of locking pliers to try to grab onto it. Using my 15-millimeter socket, I'm going to come down from the bottom here. Now I'm going to use my 14-millimeter socket down along the bottom here, see if we can get this to come apart. Looks like it's starting to turn.
Okay. So, for us, the outer sheath on this broke free from the bolt itself that's supposed to be running through the center, so I'm just going to go ahead and spray this down with some penetrant, let that soak down and through there. Sometimes, what happens is, is this outer portion will actually freeze or get stuck onto the bolt. If that's the case, what you would either want to do is grab onto the outer portion with some locking pliers, and then try to spin out that bolt. If that doesn't work, you might have to just cut the bolt itself. There's the bolt. Let's get all this out of here. Awesome.
So, now, assuming you're doing the sway bar links as a pair, now is the best time to go ahead and start doing the other side as well. Okay. Once you have both sides out, you should be able to move the bar around a little bit at this point. We're going to grab our new sway bar links. We take off the nut, take off the washer and the bushing, the washer and the bushing, and then, of course, the sheath, washer and bushing again, and we're going to leave it just like this.
Now, as we come up, okay, coming up from under the control arm, we still have the bolt with the washer and the bushing. Now we're going to take our bushing with our washer, put that facing down and towards the control arm. Grab your spacer, put that on there. We're going to push this up a little bit further. Now you're going to go washer, facing up, bushing. Get it underneath that sway bar. Bring it up. Bushing again.
If you were to look at these bushings, you can tell that they have like a rounded area, and then they have this area right here with a little like a piton. The piton is going to be going either towards the control arm or towards the sway bar. Set that on there, this one right here, and then, of course, our locking nut. I like to use a little thread locker on these.
I'm just going to use my 14-millimeter wrench, and of course, my ratchet underneath, and I'm going to start snugging it up. As I snug it, I want to be watching these bushings. What I want to see is the bushing touching up against the bar, on both sides of course. And, of course, down by the control arm there, we want those bushings to be touching up against it as well. We don't necessarily want to continue tightening, though, until the point where they seem like they're getting squished down and even pancaking out. So, let's just snug them up so they're all touching at least, and then we'll continue on.
Okay. So, this looks great. As you can tell, all of my bushings are touching exactly where they need to be touching. And you're also going to notice that I didn't continue tightening until they flattened out, like I had said before. This looks pretty great, so I'm just going to take a quick measurement of it. It looks like it's approximately the width of my thumb, personally, so I'm going to make sure that I go approximately the same on the other side of the vehicle.
Okay. Now it's going to be time to get the wheel up on here. Slide it on. Now we'll get the lug nuts on here, we'll bottom them out, and then we'll torque them to manufacturer specifications. Let's torque these lug nuts to 140 foot-pounds. Torqued.
