Gates (TCKWP298) Water Pump and Timing Belt Component Kit

This Gates timing belt component kit, tensioner with water pump is just what you need to keep your vehicle in good running order.

Our timing belt sets come from a company that is committed to supplying components that are engineered and manufactured under strict quality control procedures. They are leaders in timing component quality which provides you with the highest quality parts available on the market.

This high quality, water pump and timing belt kit, contains the following pieces and has the following specifications:

  • (1) - Timing Belt
  • (1) - Tensioner
  • (1) - Hydraulic Tensioner
  • (1) - Idler
  • (1) - Water pump
  • (1) - Water pump gasket

Most car manufacturers recommend changing your timing belt between 50,000 and 70,000 miles (consult your owner's manual to see what your specific manufacturer suggests).

These parts are authentic Gates brand products that are supplied and packaged by Gates. Some of the components included in this kit may be sourced by Gates from other high quality suppliers such as Aisin, GMB, Koyo & other OEM suppliers. These parts are subjected to the very same testing and quality standards as all Gates products.

Item Condition: New

2 Year Warranty

This item is backed by a 2 Year Warranty. In the event this item should fail during intended use, we will exchange the part free of charge (excludes shipping charges) for the original purchaser.

  1. step : Beginning the Repair (0:37)
    • This is Part 2 of a two part video
    • Please consult Part 1 for earlier instructions
    • Perform the steps outlined in Pat 1
  2. step : Positioning the Engine (0:52)
    • Use a 22mm socket to turn the crank pulley and rotate the engine into the correct position
    • The white mark on the crank pulley should line up with the 0 marker
    • The indentation of the passenger side (right) cam should line up with the timing mark
    • The indentation of the driver side (left) cam should line up with the timing mark
  3. step : Removing the Harmonic Balancer (1:21)
    • Remember to put aside any parts you remove in an organized fashion
    • Use a 22mm socket and an impact wrench to remove the crank pulley nut
    • Bolt the harmonic balancer puller to the harmonic balancer
    • Tighten the bolts 5 or 6 turns
    • The bolts should be visible on the back side of the harmonic balancer
    • Thread the larger bolt into the harmonic balance bolt
    • Pull off the harmonic balancer
  4. step : Removing the Crank Sensor Ring (2:46)
    • Remove the four 10mm bolts from the crank shield
    • Remove the crank sensor ring
  5. step : Removing the Old Belt (3:58)
    • Remove the 12mm bolts from the belt tensioner
    • Pull off the tensioner
    • Pull the crank position sensor wire aside as necessary
  6. step : Removing the Pulleys (5:06)
    • Remove the 13mm bolt from the tensioner pulley
    • Remove the tensioner pulley
    • Remove the 14mm bolt from the idler pulley
    • Remove the idler puller
  7. step : Removing the Water Pump (5:18)
    • Remove the studs/bolts from the water pump using a 12mm wrench
    • Remove the remaining bolts
    • Make sure all the bolts are removed
    • Carefully pry the water pump off using a screwdriver
    • Carefully pull off the water pump gasket, keeping the rubber in one piece
    • Scrape off any residue or dirt with a razor blade
  8. step : Installing the New Water Pump (7:13)
    • Slide the new gasket into place
    • Remove the o-ring
    • Install the new o-ring
    • Slide on the new water pump
    • Move the cam sensor wire aside as necessary
    • Install and hand tighten the water pump fasteners
    • Use the socket to tighten the fasteners
    • Tighten opposite fasteners in order
    • Use a torque wrench to tighten the fasteners to 17 foot-pounds of torque
    • Reinstall the plastic block-off plate
  9. step : Installing the new Tensioner (9:34)
    • Install the tensioner spacer
    • Install the tensioner
    • Thread the tensioner bolt
    • Tighten the tensioner bolt with a 3/8 inch Allen wrench
    • Make sure the tensioner pivots freely
  10. step : Installing the New Idler Pulley (9:59)
    • Install the new idler pulley
    • Begin threading the bolt by hand
    • Tighten the bolt with a 14mm socket
  11. step : Installing the New Timing Belt (10:12)
    • The timing belt has three markers: CR, R-CAM, and L-CAM
    • See [3:37] for more information
    • Line up the CR marker with the white dot on the crank
    • Line up the L-CAM marker with the timing marker on the left cam
    • Line up the R-CAM marker with the timing marker on the right cam
    • Wrap the belt around the crank and left cam
    • Lightly pull the left cam as you stretch the belt onto the right cam
    • Push the belt onto the right cam
    • Check that all the timing markers are lined up
  12. step : Reinstalling Other Timing Parts (13:20)
    • Reinstall the tensioner
    • Reinstall the crank sensor wheel and crank shield
    • Reinstall the harmonic balancer and crank pulley
  13. step : Checking the Timing System (14:22)
    • Check that all the timing marks line up properly
    • Turn the crank pulley with a socket and breaker bar to rotate the engine
    • Make sure the timing marks still line up properly
  14. step : Reinstalling the Other Engine Parts (15:19)
    • Reinstall parts to the front of the engine by reversing the steps outlined in Part 1

Tools needed for replacement:

    Air Powered Tools

  • 1/2 Inch Air Impact Gun

  • General Tools

  • Drain Pan
  • Floor Jack
  • Jack Stands
  • Razor Blade / Gasket Scraper

  • Hex Wrenches

  • 3/8 Inch Allen Wrench

  • Pliers, Cutters & misc Wrenches

  • Slip-Joint Pliers

  • Ratchets & Related

  • 1/2 Inch Breaker Bar
  • Ratchet
  • Socket Extensions
  • Torque Wrench

  • Screwdrivers & Related

  • Flat Blade Screwdriver
  • Phillips Head Screwdriver

  • Sockets - Metric

  • 10mm Socket
  • 11mm Socket
  • 12mm Socket
  • 13mm Socket
  • 14mm Socket
  • 15mm Socket
  • 16mm Socket
  • 17mm Socket
  • 18mm Socket
  • 19mm Socket
  • 20mm Socket
  • 21mm Socket
  • 22mm Socket

  • Specialty Tools

  • Harmonic Balancer Holding Tool
  • Harmonic Balancer Puller

  • Wrenches - Metric

  • 10mm Wrench
  • 11mm Wrench
  • 12mm Wrench
  • 13mm Wrench
  • 14mm Wrench
  • 15mm Wrench
  • 16mm Wrench
  • 17mm Wrench
  • 18mm Wrench
  • 19mm Wrench
  • 21mm wrench
  • 22mm Wrench

4.71/ 5.0
7 reviews
5 Stars
4 Stars
3 Stars
2 Stars
1 Star
Fit just like the OEM
Only complaint is waterpump gasket was bent. Should do a better job packing it.
April 23, 2017
Was a lot of work but rewarding
It was a job but the video on 1 A Auto is a must. It took me about 10 hours but I’m slow but the was start to cleanup time. It was good to take a few breaks and had a beer. So glad to have saved the money and have that feeling of accomplishment.
November 21, 2017
a kit that i cannot get in my home town
I havent installed it yet but these are top notch replacement parts.All of the parts look and feel excellent.and thanks for the videos.
February 20, 2019
4.7 timing belt kit
watched the you tube video. followed the instructions and 5 hours later test drove. no problems. would recommend purchasing the thermostat and gasket and radiator hoses to make it a complete job.
March 4, 2019
Quality kit, everything included
Very complete kit with all quality stuff. I felt like I owed 1A AUTO my business after the excellent video that made the job so much easier. I would watch a portion of the video, pause it, do that step then move on etc. I tried not removing the radiator but when it was time to get my impact wrench on the crank bolt it wouldnt fit. Bottom line follow instructions and save the $500 plus labor cost the stealership charges.
March 13, 2019
Timing belt
Perfect fit, very happy.
March 18, 2019
Great fit, kit had everything needed
The YouTube video instruction was excellent. One of the all time best instructionals on the web. Nice job.
June 30, 2019
Will this fit my car? Add a vehicle to make sure
Customer Q&A
Ask a question to 1A Auto customers who purchased the product
There is no mention of replacing the thermostat in this whole process. What are your thoughts on this? I looked it up, why is this so expensive?
Michael W February 3, 2019
The thermostat is not included in this particular kit as it does not come that way from our vendors.
Emma F February 3, 2019
Year Make Model Description
1998-2000Lexus GS400 Lexus GS400 Timing Belt Kit with Water Pump V8 4.0L Gates TCKWP298
2001-2007Lexus GS430 Lexus GS430 Timing Belt Kit with Water Pump V8 4.3L Gates TCKWP298
2003-2009Lexus GX470 Lexus GX470 Timing Belt Kit with Water Pump V8 4.7L Gates TCKWP298
1998-2000Lexus LS400 Lexus LS400 Timing Belt Kit with Water Pump V8 4.0L Gates TCKWP298
2001-2006Lexus LS430 Lexus LS430 Timing Belt Kit with Water Pump V8 4.3L Gates TCKWP298
1998-2007Lexus LX470 Lexus LX470 Timing Belt Kit with Water Pump V8 4.7L Gates TCKWP298
1998-2000Lexus SC400 Lexus SC400 Timing Belt Kit with Water Pump V8 4.0L Gates TCKWP298
2002-2010Lexus SC430 Lexus SC430 Timing Belt Kit with Water Pump V8 4.3L Gates TCKWP298
2003-2009Toyota 4Runner Toyota 4Runner Timing Belt Kit with Water Pump V8 4.7L Gates TCKWP298
1998-2007Toyota Land Cruiser Toyota Land Cruiser Timing Belt Kit with Water Pump V8 4.7L Gates TCKWP298
2001-2009Toyota Sequoia Toyota Sequoia Timing Belt Kit with Water Pump V8 4.7L Gates TCKWP298
2000-2009Toyota Tundra Toyota Tundra Timing Belt Kit with Water Pump V8 4.7L Gates TCKWP298
