Assemblies may include halogen or incandescent test bulbs that should be replaced before installation.
Attention California Customers:
WARNING: This product can expose you to chemicals including Chromium (Hexavalent Compounds), which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov
Lifetime Warranty
This item is backed by our limited lifetime warranty. In the event that this item should fail due to manufacturing defects during intended use, we will replace the part free of charge. This warranty covers the cost of the part only.
FREE Shipping is standard on orders shipped to the lower 48 States (Contiguous United States). Standard shipping charges apply to Hawaii and Alaska.
Shipping is not available to a P.O. Box, APO/FPO/DPO addresses, US Territories, or Canada for this item.
Expedited is available on checkout to the United States, excluding Alaska, Hawaii.
Final shipping costs are available at checkout.
Created on:
Tools used
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the internet.
Hi, I'm Mike Green. I'm one of the owners of 1A Auto. I want to help you save time and money repairing and maintaining your vehicle. I'm going to use my 20-plus years experience restoring and repairing cars and trucks like this to show you the correct way to install parts from 1aauto.com. The right parts installed correctly. That's going to save you time and money. Thank you and enjoy the video.
In this video, we're going to show you headlight removal and installation on this '04 Ford Ranger, pretty much the same for any '93 to present Ranger and no tools are necessary. Headlights on these Ford Rangers are really quite nicely designed and pretty easy. There are two tabs that you pull up on right back here. Once you have those tabs up, just pull your light forward. Now, here's the bulb. You can access the bulb easily. Pull this protector off and then your turn signal bulb, you twist, and it comes out, and your light is out. Obviously, you can service the bulbs.
The headlight bulb, you twist this, pull it out, and then you can pull the bulb out. Here's our original light, and here's the new light from 1A Auto. Now, obviously if your original light has been broken or something, you're going to want to replace it with a new one. You can also see, this truck doesn't have many miles on it, so the lens isn't too cloudy or faded, but if you drive your truck a lot of miles or in sandy conditions, these lenses can get pretty chipped up and clouded. A nice easy way to fix that is to just put a new set of lights in. You can see our lights are going to mount in the same. They have all the same connectors and everything so everything is going to go in just like the original.
One tip is before you put the new light in, just try and match it up with the distance. You can see that this adjuster is pretty close to the light there, so just preliminarily aim it. Take your new light and just try and get that just about the same distance. For now, obviously this light is fine, so we're going to put it back in the truck. Installing is just the reverse of the procedure. Put your signal in first, turn and lock, plug your light bulb in, and then carefully place it back in there.
I'm kind of looking down to make sure that all the adjusters are going into their holes properly. The lower one here is just a little bit off. There we go. Down there, just make sure that is all the way through. Then on this side, make sure that one there and the one down below, which is hard to see. Make sure those are all the way in. Push it really good. Push down on your tabs. You can see that mine's not in very well. Put it back up here. Push down and mount it nice and secure.
We hope this helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the internet. Please feel free to call us toll free, 888-844-3393. We're the company that's here for you on the internet and in person.
Tools used
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike Green. I'm one of the owners of 1A Auto. I want to help you save time and money repairing or maintaining your vehicle. I'm going to use my 20-plus years experience restoring and repairing cars and trucks like this to show you the correct way to install parts from 1AAuto.com. The right parts installed correctly: that's going to save you time and money. Thank you and enjoy the video.
In this video we'll be showing you how to replace the fog light on this 2004 Ford Ranger, same as any '04 or '05, and similar for other years of Ranger. You'll just need some basic tools, some various millimeter sockets and needle-nosed pliers.
All right, to do a fog light on a Ranger Edge here, you're going to need to remove this 8mm bolt right here, okay. This is a tire, so we're looking at the fender or the bumper. We're going to remove this 8mm bolt. Now, so viewing it from kind of the middle of the car in, you want to take a regular pair of needle-nosed pliers and there's these little locking washers here. Once you get them turning sometimes, if you work on it, you can probably save them, but most of the time you may just want to twist them off. You kind of break them. Then I'll get the other one too. Okay, and then these speed nuts are 11mm, and there's kind of a long stud, so put the socket on there.
Here's your bulb. If you're just looking to replace the bulb, obviously, you just pull it out, twist it and pull it out; it's a halogen bulb, so you don't want to touch it, if your bulb's still good. You don't want to get your finger oil on it. Once you have these nuts off from that bolt, then you just kind of pull from the outside, comes off, and there's your fog light out.
So here's our original fog light, and a new fog light from 1A Auto. You can see all the holes and everything are all the same. Your bulb's going to go in there all the same, and it's just going to fit. Obviously, if your fog light got broken by a rock or something this is what you need, or maybe you just want to freshen up the car. You can see our new one is quite a bit clearer and brighter than the old one. So, reinstallation is pretty quick. Put the fog light up in there, put it on those plastic studs, and push it onto the bumper tab there. Start the speed nuts, and put our 8mm bolt in. Actually, you put the bulb in, then the 8mm bolt. Then just one tip: If you put a new one in, there's a space here between here. This is the adjusting screw, and you can adjust it up and down, and there's a space between the light assembly and the bracket, and on your new light you want to just set that at the same as the old light, and that'll be a good preliminary aim.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
