2015 Ford C-Max Rear Driver & Passenger Side Upper & Lower 4 Piece Control Arm Set TRQ PSA62120

Oh, hey friends. It's Len here at 1A Auto. Today, I'm working on a 2011 Mazda 3, and I'm going to be replacing the upper control arm in the rear. It's going to be a very easy job. I want to be the one that shows you how to do it. If you need this or any other part, you can always check us out at 1AAuto.com. Thanks.

Okay, friends, so here we are. We've got the vehicle partially supported off the ground, but the wheels still touching so it can't spin. We're going to use our 21 millimeter socket and we're going to loosen up all of these lug nuts. Okay. Just give them a crank or two. This is just to break them free, in case you're not using an air gun to do this job. If you are, well, you don't really have to worry about doing this part. Now that all five of these are loosened, we can go ahead up with the vehicle. We'll make sure that it's secured safely, so it can't shake around or fall off or anything like that. We'll move ahead to the next step.

All right, so now we're going to go ahead and fully remove these lug nuts. I'm going to take off three of them. The fourth one, I'm going to take all the way off, put it back on a few threads and then I'll remove the last one. There we are. Just going to put this one on a few threads like I said. That's just going to help keep this wheel from falling off, and potentially hurting me while I put all this stuff away. Hold the wheel, our lug nuts, we'll slide this out of the way. On to the next step.

All right, let's get our 17 up on there. There we are. I'm using a swivel socket. Let's get that up on there. I've got a nice long extension on there. I'm going to use this nice long ratchet. Oops. I'm going to remove this bolt, and we'll move ahead to the next step. Pretty sure it's all the way dethreaded. It's just being held in there now with the pressure, I'm having the other side on. I'm going to come right up top here, and I'm going to take out this 17 millimeter headed bolt. This also holds a bracket on for the flex hose here, okay. Once we take this off, we're just going to set that aside, and we'll get the bolt right out of there. Get this out of here. There's our outer bolt, has a little shank area on it right down near the end. We'll set this aside, and move onto the next step.

All right, now we're just going to stick our pry bar in here. See if we can get this arm to pry its way out. There we are. Okay. Got our brake flex hose here, so you want to make sure that you don't put too much pressure on that. Once we have this loose enough, theoretically, I should be able to put my hand up in here, pull out the other bolt. This bolt is also shanked towards the end here, so it feels as though they're about the same. We'll set this aside, get this arm out of here at the same time. Maybe. There we are. Let's move ahead to the next step.

Here we are, friends, a quick product comparison for you. Over here we have our rearward upper control arm out of our 2011 Mazda 3, and over here we have our brand new quality 1A Auto part. These two parts are built the exact same. They have the same exact shape and the same exact mounting holes. We'll line them up with each other so you can see, sitting right on top of each other. Everything lines up perfectly. We've got our two mounting holes here, mounting holes there, same curvature, super important. It's made out of quality steel right here, and it even comes with brand new bushings. With all that said, I don't see any reason why this wouldn't be a great part to install into the vehicle, so I'm going to go ahead and do it. If you need this or any other part, you can always check us out at 1AAuto.com. Thanks.

Okay, so now when we install this, we've got the part that comes down drastically, and then it comes off and it kind of levels out. It's kind of like the longer area here. The longer area is going to go towards the outward portion of the vehicle, or towards the wheel, okay? So it's going to be sitting inside the vehicle just like this. Let's go ahead and get this installed.

I'm going to try to come right in through up here. Try to get the top area in first. I've just going to get the hoses out of the way. There we are. Okay. I'm going to grab one of my bolts, bring my arm up and across the top here again. Oh, wow. Yeah. It's fun. Shooting blind here. Ooh, nice. That's a good noise. Okay. I've got a few good threads. Get my arm back out of here. Now, we're going to work on doing the upper portion. Getting this in here is going to be a little bit difficult, but we can do it. What I'm going to do, I'm going to take this little bracket off of here. Actually, I'll use it. I'll just keep it right out of the way, just like that. Why not? Just give this a couple loving bonks, see if I can get it down in there. Okay. All right. This in here. Get our bolt through. There we are. 17, let's go ahead and snug this right down. Okay. It's bottomed out, tight. We'll move ahead to the next step.

All right, so now we're going to go ahead and tighten up the upper bolt for the upper control arm in the rear here. 17 millimeter, got a universal, or I guess a wobble socket on there. Universal socket 17. I'm just going to go ahead and snug it right up here. There we are. Okay. It's bottomed out. There were are, nice and tight. Let's get our tool out of here. All right, next step. Okay, so now it's time to get the wheel up onto the vehicle. Instead of going in front of it and trying to lift and potentially hurting our back, you just come around the side of it, roll it right up your leg, and use your ab muscles to lift it up. There we are. Hold your wheel. Make sure it can't go anywhere. There we are. Our next step is going to be to bottom these out and then we'll bring it down completely and torque them down.

Okay, so now that we have all the lug nuts started on here, what I'm going to do is I'm just going to bottom them out. When I go to bottom them out, what I'm going to do is I'm going to go in a star pattern. Boom, boom, boom, boom, boom, okay? Basically, crisscross pattern, and that's to ensure I'm not going to go around in a circle this way, the wheel is not going to get kinked on just like this, and I think everything's nice and tight, you drive it down the road, the wheel's going like this. Next thing you know, you're breaking studs, your wheel comes off, God knows what could happen. Let's avoid that. Let's go crisscross star pattern. Okay. I'm not making them very tight, I just wanted to bottom them out. Now I'm going to go ahead and torque them down.

Okay, so here we go. We're going to go ahead and torque these down. We're going to make the same star pattern in a crisscross manner. 21 millimeter, 85 foot-pounds. I could have probably brought it down another inch. Okay. Just to be sure we torqued them all, let's just hit them again. Cool. Easy peasy.

Thanks for watching. Visit 1AAuto.com, your place for DIY auto repairs, for great parts, great service, and more content.

Hey friends, it's Len here at 1A Auto. Today we're working on our 2001 Ford Focus ZX3 and I want to show you how to do a rear upper control arm. It's going to be very simple. I can do it. You can do it too. If you need this or any other part you can always check us out at 1AAuto.com. Thanks.

Okay, so one of the first things we have to do is take off the wheel obviously. We're going to remove our lug nuts. These are missing the caps. Usually they have a chrome cap on them that would make them 19s. These are actually closer to an 18 so that's what I'm going to use to remove it. But generally speaking, you're going to use a 19 to remove your lug nuts. Leave that one on there a little bit. That's just going to help prevent the wheel from falling off when I take off the last one. Set this aside. Take off our wheel, set it aside.

Here's the arm. We're just going to take it, bring it right into the vehicle, to the approximate area where the old one is. Just make sure it's the same shape. Everything lines up right. Make sure we're dealing with the right beast. This is it. Looks good. Right up here, you've got a mounting bolt. It's a 15 millimeter head. I'm going to use 3/8ths drive because my 1/2 inch drive is a much longer ratchet and I just don't think I can probably get it in there. I'm sure if you used an extension, a universal 15 millimeter socket, air gun could probably figure something out a little quicker here, but I'm not going to worry about that right now. I just want to show you how to get it out of here.

I just threw on an extension with a swivels universal socket gives me a little bit more space to be able to swing my ratchet. It feels like it's in there pretty good. Get that one pretty loose. Let's go ahead and loosen this one up. The whole bolt at this point, it's just kind of threading its way out because this is under tension trying to come this way.

It's our bolt. Just comes right through here. Now that we have that one out, I can come back here, grab this one. That's the inside upper bolt there. Looks like it's about the same as this one, but we won't mix them up. Set that aside. Try to grab this arm out of here. There it is. Easy peasy.

Here we are friends, a quick product comparison for you over here. We have our original upper control arm out of the rear of our 2001 Ford Focus ZX3 hatchback. And over here we have our brand new quality 1A Auto part. Both these parts are created the exact same. They have the same shape, the same mounting bushings. To show you, I'll just line them up real quick. As you can tell, same shape, same mounting bushings. They're the exact same. With that said, I don't see any reason why this wouldn't be a quality part to install onto the vehicle, so I'm going to go ahead and do it. If you need this or any other part, you can always check us out at 1AAuto.com. Thanks.

Okay, so this is how it's going to go inside the vehicle. Just like this. You've got where it swoops down at a sharp angle. Then it comes back up and it just kind of hangs out and comes out this way. The area where it comes up and out is going to be the outer area where it goes here. This area is going to go up and in there. Grab my bolt. Can use thread locker if you'd like, it's your prerogative. For the purpose of this video, I'm not going to worry about it. I'm just going to take my bolt. First. I'm going to get my arm up in there.

Now I'm going to get my bolt through my hole. Just start it in a couple of threads here. Not going to tighten it up or anything. I just want it to be in and the threads so I don't have to worry about stripping anything. Now here comes the hard part. Remember I was telling you that it had pressure. Look at how much, how far away this is and the angle. It's going to be a little difficult. If you happen to have a ratchet strap, it's going to come in handy. Let's give it a try. I just got my ratchet strap set up down along the bottom here. I brought it up through, along here, up around this stud and then down around this way and I'm just kind of using the ratchet strap to pull me in. Grab a pry bar. I'm going to have to resituate it.

Brought it down along the bottom there, up and over across, in between the coil spring here, over the lug nut area, and then just over to this side. And that's just so I can draw this in. Now I just need to get this lined up. See if I can get this to turn a little bit from the other side. Looks like it's close but not close enough.

Get almost. Getting this upper one lined up is just really interesting. Get this bolt so it's turning in there. Once we get it so it's definitely in a few good threads, we'll go ahead and get this ratchet strap out of here. It's definitely in. We'll relieve our ratchet strap. I'm just putting a jack underneath here. I'm trying to bring the suspension up to the point where if this vehicle had its wheel on and it was sitting on the ground, it would have that amount of pressure on the suspension. Sitting at curb height is what you would say. That's it right there. that's as far up as it's going to go because our lift is happy there.

Now I'm just going to go ahead and snug up these bolts and then we'll torque them to 85 foot pounds. We'll go 85 foot pounds. Just going to hit it one more time. All right. And do the inside one. There it is. Hit it one more time. All right, both of those are tight. There we are. Just going to wheel it up my leg. Cool. We've got our lug nuts. We're just going to snug up these lug nuts. There we are. Bring it down, torque them up. Here we go, we're going to torque these down to 94 foot pounds with our torque wrench. Go around again. There we are. Do the same to the other side of the vehicle.

Thanks for watching. Visit 1AAuto.com for quality auto parts, shipped to your door. The place for DIY auto repair. And if you enjoyed this video, please click the subscribe button.

Hey friends, it's Len here at 1A Auto. Today we're working on our 2001 Ford focus ZX3 hatchback and I'm going to be replacing a rear control arm. It's going to be super simple. I can do it. You can do it too. If you need this or any other part, you can always check us out at 1aauto.com. Thanks.

Okay, so one of the first things we have to do is take off the wheel obviously. We're going to remove our lug nuts. These are missing the caps. Usually they have a chrome cap on them. That would make them 19s. These are actually closer to an 18, so that's what I'm going to use to remove it. But generally speaking, you're going to use a 19 to remove your lug nuts. Leave that one on there a little bit.

That's just going to help prevent the wheel from falling off when I take off the last one. Set this aside. Take off our wheel. Set it aside. We've got our rear arm here. This is an alignment adjustment. So what you want to do is just mark this with an area on your frame. Oops, here we go. Now I get two crowns. Cool. Cool. All right. So the reason for this is so that when we're putting it back together and we go to tighten it up, we're going to have this alignment camber adjustment right to where it's supposed to go. All right, so first thing we're going to do is loosen this up. These my 19 backside here, 18 on the side closest to me.

Let's leave that nut on there for now. Just going to move around. See how that changes everything here. This pivots and that's going to angle your wheel. So that's the importance of making your markings. All right, we'll leave that like that. Important to note. I've got pressure right here. It's holding up this arm. All right. Not too much pressure. I'm not, you know, lifting the vehicle up off the lift or anything. But the reason for that is so that when I take this bolt out, if this spring is under any tension, I want to be able to control how fast this arm can come down. So this can't just come flying down, potentially hurt me. We're going to remove this bolt. It has a welded nut on the backside. This is a 15 millimeter.

I'm just going to try to maneuver this so that I'll be able to get this bolt out of here. Maybe up, maybe down. Guess we'll have to see which way it needs to go. Getting a little bit more slack here. Okay. Here's our bolt. Set this aside and we can slowly lower this down. There it is. All right. It's like we still get a little bit of spring tension here. It's the reason for having this here. I can bring it down at my own leisure. I know I'm safe. The springs aint coming flying out. I'm just going to bring the vehicle up a little bit more so it'll relieve a little bit more tension.

Here we are. Let that hang. Here's our rear coil spring. Get this nut off of here. This right here has a slot in it and that slot lines up with that divot on the adjustment washer there, so that way there when you turn this backside of the bolt, it turns that and it does what I showed you before. Let's get this out of here. See if I can get my bolt out and through. Here it is, and here's our rear lower control arm.

I'm just trying to get this rubber off of here. Do whatever you have to do to get it off because we want to switch it over to our new control arm. Here we are. Here it is. The reason why it's so hard is because right along here there's a little lip and that just holds on inside there. Over here we have our lower control arm out of the rear of our 2001 Ford focus ZX3 hatchback. Over here we have our brand new quality 1A Auto part. Both these parts are created the exact same. They've got the same shape as you could tell. Same length, super important. You got your mounting holes, right? And then up here, same. And then of course even the spot for the little rubber jounce bumper there.

This brand new quality, 1A auto part has everything that we need. With that said, I don't see any reason why I wouldn't want to install it into the vehicle. So I'm going to go ahead and do it. If you need this or any other part, you can always check us out at 1aauto.com. Thanks.

So here's our adjustment piece, right? That's the side that I was holding with the wrench. Came through this way and we have our adjustment washer. You can see where it slides into the groove right there. And then we have our neoprene locking nut. Generally speaking, these are reusable. If you felt the need, you could use thread locker on it to make sure, but it should be good to go. So this is the way it's going to go in. Just like this. Just going to go through this sub frame, right through there and hold our lower control arm. Got our control arm, just let me see if I can get this up and in here. There we are. That lines up.

Just going to start this on here. We're not going to tighten this up yet. Let's move ahead to the next step. So right inside the lower area of the control arm there, you can see there's like a little groove, comes around and it stops there. That's where the end of your coil springs is going to rest up against. So you want to make sure when you're installing this, you have the end of your coil spring right up against where that hole is. To be able to confirm it you could just look through the hole once you're starting to get it up in there.

So it looks as though I'm going to go just about right here. So I want to get this ready. I'm going to bring this up and in. Turn it as needed here. Looks like that should be it. See about bringing this over. Cool. I'm going to grab my safety glasses. Super important in case this thing slides out. The arm comes down and the spring wants to come and try to hurt me for some reason, even though I did nothing wrong. Accidents happen.

Before we go too far with that though, I'm going to grab my rubber bushing. I'm just going to see about trying to get the rubber bushing onto the new arm. There it is. And now we'll go up. As we bring this up, whether it's with a floor jack or a bottle jack, whatever it is you're using, it's applying pressure to the spring, trying to compress it. So you need to keep that in mind. If this decides it wants to come out and let this arm down, this spring's going to want to do something kind of crazy. And so just get out of the way if something happens.

Here we are. I'm just going to try to line up my bull hole here. Whatever you got to do to get it lined up. Your situation may be a little different than mine, but that looks pretty great right here. I'm just going to go from the rear of the vehicle towards the front. Lower this down a little bit and see if I can bring that up. Okay.

So right now it's through this part, but this actually needs to come through at an angle like this. So now that we've got it through this side, I'm going to go ahead and lower this down and then I'm going to try to grab just a little bit further over on the forward side of this and see if I can get it to go up at an angle. Right up in here.

Okay. So I got my bolts started in here. I got a couple threads. The way that I did it is, I just kind of jacked up along the side right here so I can tilt the lower control arm's coach to get it to line up with this because it's not sitting parallel to the ground. All right. You could use something like a ratchet strap if you have a ratchet strap or whatever you have to do to make it happen. So to continue, I'm just going to take this, I'm going to bottom it out and then I'm going to go ahead and bottom out the other side. And then we'll torque them down. Before we go too far with bottoming this out, what we're going to do, we're going to bring up the suspension. It's high enough, maybe down a little bit. There we are.

Just bring it up so that way there the suspension's compressed as if the vehicle was sitting on the ground. All right. So it's under load right now. Okay, let's bottomed out. We'll torque that in a minute. We're going to come up here and tighten these. Okay. It's time to start snugging this up. You'll notice that as I turn this back here, I'm moving my marks. Okay, so use your wrench, line up the mark with where you want it and then go ahead and use the ratchet on the rearward side of the bolt or rear side of the car to snug it up once you have it lined up with where you want.

It doesn't need to be perfect, just want it to be close because after you're done this service, you're going to want to bring it down to a reputable shop and go ahead and get an alignment anyways. So this is just going to get a close for the next person that's going to be doing it for you. We've got that snugged up. We've got this snugged up. Let's go ahead and torque them down. We're going to torque this down to 85 foot pounds with our torque wrench. I'm holding the backside.

There we are. I'm going to go ahead and do it one more time. Tight. We'll move along to here. I'm going to switch over to my 15. All right and hit it again. Torqued. Torqued. Get this out of here. Onto the next step. Here we are. Just going to wheel it up my leg. Cool. We've got our lug nuts. We're just going to snug up these lug nuts. There we are. Bring it down, torque them up. Okay, so here we go. We're going to torque these down to 94 foot pounds with our torque wrench. Go around again. There we are. Do the same to the other side of the vehicle.

Thanks for watching. Visit 1aauto.com for quality auto parts shipped to your door, the place for DIY auto repair. And if you enjoyed this video, please click the subscribe button.
