Replaces
Recommended for your 2002 Ford Expedition
Replaces
$34.95
Part Details
Specifications
About TRQ:
TRQ is a trusted brand dedicated to making every repair a success story by combining premium parts with easy installation. Each TRQ part is engineered by a team of automotive experts to meet or exceed OEM standards, delivering enhanced performance and maximum longevity. With rigorous in-house testing, the brand ensures superior fit and function across every product line. TRQ also provides customers with best-in-class, step-by-step installation videos—so you can complete repairs with confidence, whether you're a first-time DIYer or an industry professional.
Product Features
TRQ suspension kits are manufactured using premium raw materials and coatings for extended service life. Each TRQ suspension component is designed to be a direct, maintenance-free replacement to the stock unit. To extend the life of your steering and suspension components, TRQ recommends replacing components in pairs, sets, or kits. All products are fit and road-tested in our Massachusetts R&D facility to ensure we deliver on our promise of Trusted Reliable Quality.
Install Tip: When replacing steering components, have a professional alignment performed afterwards. This ensures proper tracking and even tire wear.
Our steering and suspension components are pre-greased and sealed for long life and do not require the extra maintenance typically required by greaseable versions.
Attention California Customers:
WARNING: This product can expose you to chemicals including Lead and Lead Compounds, which are known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Lifetime Warranty
This item is backed by our limited lifetime warranty. In the event that this item should fail due to manufacturing defects during intended use, we will replace the part free of charge. This warranty covers the cost of the part only.
FREE Shipping is standard on orders shipped to the lower 48 States (Contiguous United States). Standard shipping charges apply to Hawaii and Alaska.
Shipping is not available to a P.O. Box, APO/FPO/DPO addresses, US Territories, or Canada for this item.
Expedited is available on checkout to the United States, excluding Alaska, Hawaii.
Final shipping costs are available at checkout.
Created on:
Tools used
Hi, I'm Mike from 1A Auto. We've been selling auto parts for over 30 years. We're dedicated to delivering quality auto parts, expert customer service, fast and free shipping, all backed by our 100% satisfaction guarantee. Visit us at 1AAuto.com, your trusted source for quality auto parts.
So, when we're going to start this project, we're going to go ahead and loosen the lug nuts on the wheel. We're going to use a breaker bar with a 19 mm socket. Next, we're going to go ahead and raise and support your vehicle. You can use a jack and jack stands. In this case, here, we're using a lift to make it a little bit easier. We just go ahead and remove the lug nuts here, just by using that socket, because we already loosened those. With the lug nuts removed, we can now go ahead and remove the wheel and tire.
Right about here, we have your sway bar or anti-sway bar end link, here. Here's your sway bar. In most cases, here, you'll find these sway bar end links broken. What we're going to do is we're going to show you how to go ahead and remove this and do an installation for you. This component, here, can actually be removed and replaced with the tire still on the vehicle. We just happened to have the vehicle up in the air with the tire off so it just made it a little bit easier. This is something you can do with the tire still on there.
All right, so we're going to use a 14 mm on the head of the bolt down below, and we're going to use a 14 mm on the top. It may vary on your application. I'm going to go ahead and remove this nut here. Now, this does come off in stages. You have your main washer. You have your rubber of poly bushing. Then, obviously, you have the sway bar link here, or the sway bar itself, anti-sway bar. I'm going to try and just tap this down. This bolt will slide out through the bottom. What we don't want to lose is all these components in the middle here. We're going to show you what those do. Before we pull this out, we're going to go ahead and start pulling apart the internal pieces here.
Here is your complete anti-sway bar end link. You can actually see it just starts off with just a basic bolt. Then you have your metal collar here. You want to make sure that that slides on so that the dish part is facing upward. Then you're going to take your component here. Your bushing could be a poly or rubber bushing. Slide that down. Now, this is going to go up inside the control arm. What you want to do is sleeve the components together. What's going to happen next is your next bushing is going to go on, followed by your next dish. Now this is going to go the opposite way, so it's going to compress and squeeze against its matching component. This here is simply just a sleeve. It's not threaded. Slips right down. Your next component is that there. Slide this on, and once again we're going to sleeve the other component, which is your sway bar, your anti-sway bar. That'll slip on followed by that, and followed by the nut. That there is your complete unit. Our vehicle doesn't actually need replacement, but this is just your R & R process.
Here's the reinstallation. Going to slide this up through the bottom, and go ahead and slide your bushing down, followed by that spacer and that washer. We're going to now go ahead and put the sleeve on. It's going to be the next bushing. I'm sorry, it's actually your spacer, here, first, then the bushing. Now, you have the slide this up underneath like so. You want to push that up, push that bolt up through the middle. Now, you can see the base bolt is in.
You have your bushing, collar, sleeve, collar, bushing. The bushing and the collar right there. The last component is the nut. We're going to go ahead and get the threaded on. We're going to go ahead and tighten this up with a 14 mm. As you're tightening this here, you may be wondering, "How tight do I tighten this here?" Well, basically you want to get it so that the rubber bushing expands out to roughly the diameter of the metal washers there.
I'm going to go ahead and reinstall the tire. I'm going to go ahead and reinstall the lug nuts, here. You want to get a few threads caught on all of these, here. These lug nuts are a 19 mm. We're just going to snug these, bottom it out, bottom the wheel out to the rotor. We're going to lower the vehicle down onto its own weight, and then do a final torque. With the vehicle on the ground, we're going to do its final torque of the wheel, which is between 83 and 112 foot pounds. We're going to do it in a star pattern. I'll just double check the first one. She's all set.
Thanks for watching. Visit us at 1AAuto.com for quality auto parts, fast and free shipping, and the best customer service in the industry.
Tools used
Hi, I'm Mike from 1A Auto. We've been selling auto parts for over 30 years. We're dedicated to delivering quality auto parts, expert customer service, fast and free shipping, all backed by our 100% satisfaction guarantee. Visit us at 1AAuto.com, your trusted source for quality auto parts.
So in order to start this project you want to go ahead and loosen the wheel and the lug nuts here. We're going to use a breaker bar with a 19 millimeter socket. So next we're going to go ahead and raise and support your vehicle. You can use a jack and jack stands. In this case here we're using a lift to make it a little bit easier. Just go ahead and remove the lug nuts here just by using that socket because we've already loosened those. With the lug nuts removed we can now go ahead and remove the wheel and tire.
So this right here is your outer tie rod end. We have the nut here to anchor this on. This is the castle nut. Normally you would have a cotter pin through here, but this did not have it in there. So it must have rotted or fallen out. So we're going to go ahead and remove this nut off of the outer tie rod end, and we're going to use a 13/16” wrench for this here.
So in order to remove this outer tie rod end, this actually fits into a tapered hole. What we can usually do in our driveway at home is, if you use a hammer and you strike the front here, it normally causes this to pop out. So now that we have this out, you can see that this is a tapered base, and this fits tightly into the front of the steering knuckle. So when you tighten up the castle nut, it sucks it down inside and keeps it nice and tight.
We're going to go ahead and replace the adjuster sleeve right here. We want to start by removing your outer tie rod end. Ideally, you want to count the amount of threads that this comes out on, so you have full rotation of this ball joint on your tie rod end.
Okay. We're going to use a 24 millimeter and we want to go ahead and basically unthread this off of the inner tie rod end. There we go. Now, because we're just replacing the adjuster sleeve, you can leave this jam nut right here, and when you take the new adjuster sleeve, just thread it right on up to that jam nut. There we go.
This here is the old part. This here is the new part from 1A Auto. If you notice, on the old part, we have the spot right here that has a flat section so you could put your wrench on there. Our part also has that. On the installation it is important to know that each side is a different diameter. The larger is the inner tie rod end port, and the smaller one is for the outer tie rod, so you can only put it on one way. Obviously if you have the smaller port, it just won't fit.
We're just going to go ahead and thread this on. When this threads on, you're going to notice that the wrench side is closer to the tie rod on the outer tie rod, but this here was closer to the inner. It doesn't matter. It's going to work the same exact way, it's just to give you an anchoring point for your wrench. Okay, you want to just crank that right up by hand up to that jam nut.
Now that we have the adjuster sleeve installed, because we don't actually have to replace this outer tie rod end, we can go ahead and get this installed now. In this component, we did count 31 full rotations. That means for the ball joint section facing down, a full rotation, that is one. We counted 31 of those there. In case you were installing a new outer tie rod end, you would have that count. I believe that was a 31. We'll just tighten up that jam nut by hand a little bit.
Then you're ready for your installation. Install your castle nut. You would tighten this up. Line up the castle nut with the hole in the outer tie rod end there. Use your cotter pin, feed it through, and then you're going to want to bend that over using a pair of pliers. Your adjuster sleeve may come with jam nuts. If your factory equipment is just fine, there's no need to replace them. Okay, so we're going to go ahead and tighten up these jam nuts.
All right, I'm going to go ahead and reinstall the tire. I'm going to go ahead and reinstall the lug nuts here. You want to get a few threads caught on all of these here. These lug nuts are 19 millimeters. So we're just going to snug these, bottom it out. Bottom the wheel out to the rotor. We're going to lower the vehicle down onto its own weight, and then do a final torque. With the vehicle on the ground, we're going to do a final torque of the wheel which is between 83 and 112 foot pounds. We're going to do it in a star pattern. All right, just double check the first one. She's all set.
Thanks for watching. Visit us at 1AAuto.com for quality auto parts, fast and free shipping, and the best customer service in the industry.
PSA37187
