Chevrolet Buick Pontiac Olds Rear Driver or Passenger Side Rearward Lateral Link DIY Solutions

Description
Vehicle Fit
Warranty & Shipping
How-To & Tools
Q&A

Part Details

  • Design:   Adjustable

Specifications:

  • Fits LH (Driver Side) or RH (Passengers Side) REAR
    • Bolts to rear knuckle
    • Adjustable
  • Replaces Rearward Track Bar
  • Replaces one of many dealer part numbers including: 10319450, 10329689, 10329690, 10329694, 15235586, 15236248, 20930845
  • Track bar is new, not remanufactured or refurbished
  • Includes new end bushings already installed
  • Commonly called by GM "Rear Knuckle Rod"

Your DIY Solution—Complete Repair in One Purchase

Do you need an assortment of parts to complete a repair? Stop searching for parts individually and complete your repair in a single purchase with a customized kit or set from DIY Solutions.

High-Quality Parts From Trusted Brands

Parts in DIY Solutions' kits and sets are selected from the best automotive brands and include hard-to-find and even obsolete parts you may need for your vehicle.

Guaranteed Fit

DIY Solutions ensures its selected parts are quality-tested to guarantee fit and function.

Item Condition: New

Lifetime Warranty

This item is backed by our limited lifetime warranty. In the event this item should fail due to manufacturing defects during intended use, we will replace the part free of charge.

  1. step : Removing the Wheel (0:51)
    • Loosen the lug nut covers with a 19mm socket
    • Pull off the center cap by hand
    • Loosen the lug nuts with the vehicle on the ground
    • Raise the vehicle with a floor jack
    • Secure the vehicle on jack stands
    • Remove the lug nuts
    • Pull off the wheel
  2. step : Removing the Brake Caliper (1:20)
    • Remove the two 13mm bolts from the brake caliper
    • Pry the brake pads into the caliper with a flat blade screwdriver to push in the pistons
    • Pull the caliper aside
  3. step : Loosening the Struts (1:54)
    • Remove the two 21mm nuts from the strut
    • Hammer the bolts out of the strut
    • Repeat Steps 1 through 3 on the opposite side
  4. step : Removing the Track Bar (3:05)
    • Apply penetrating oil to the track bar bolts
    • Hold the inside track bar bolt with a 21mm wrench
    • Loosen the inside track bar bolt with a 21mm socket and ratchet
    • Hold the outside track bar bolt with a 21mm wrench
    • Loosen the outside track bar nut with a 21mm socket and ratchet
    • Support the suspension carriage with a jack
    • Remove the four 18mm bolts from the carriage
    • Carefully lower the carriage
    • Remove the outside track bar nut
    • Pull the outside track bar bolt out
    • Pull down the track bar
    • Remove the inside track bar bolt
    • Pull the track bar down and out
  5. step : Preparing the New Track Bar (5:47)
    • Line up the new track bar with the old one
    • Thread a bolt through one end of both track bars to hold them in place
    • Adjust the new track bar until it matches the old one in length
  6. step : Installing the New Track Bar (6:14)
    • Raise the new track bar into place
    • Slide the inside track bar bolt and nut into place
    • Tighten the inside track bar bolt reliminarily
    • Slide the outside track bar bolt into place
    • Push the track bar onto the outside bolt
    • Fasten the washer and 21mm nut onto the outside track bar bolt
    • Raise the suspension carriage with the jack
    • Insert the four 18mm bolts into the carriage
  7. step : Reinstalling the Strut (7:54)
    • Insert the two 21mm bolts into the strut
    • Tap the bolts in with a hammer
    • Fasten the 21mm nuts onto the strut bolts
    • Tighten the 21mm nuts to 120 foot-pounds of torque
  8. step : Reinstalling the Brakes (8:34)
    • Slide the brake rotor on, if you had removed it previously
    • Put on the brake caliper
    • Insert the two 13mm bolts into the brake caliper
    • Repeat Steps 7 and 8 on the opposite side
  9. step : Tightening the Track Bar Bolts (9:04)
    • Lower the suspension onto jack stands
    • Tighten the track bar bolts
    • Tighten the track bar adjuster with two adjustable wrenches
  10. step : Reattaching the Wheel (9:40)
    • Slide the wheel into place
    • Start the lug nuts by hand
    • Tighten the lug nuts preliminarily
    • Lower the vehicle to the ground
    • Tighten the lug nuts to 100 foot-pounds in a crossing or star pattern
    • Reattach the center cap
    • Tighten the lug nut covers with a 19mm socket
    • Have the suspension professionally aligned

Tools needed for replacement:

    General Tools

  • Floor Jack
  • Jack Stands
  • Hammer

  • Materials, Fluids, and Supplies

  • Rust Penetrant

  • Pliers, Cutters & misc Wrenches

  • Adjustable Wrench

  • Ratchets & Related

  • Torque Wrench
  • Ratchet
  • A Piece of Pipe (for leverage)
  • 1/2 Inch Breaker Bar

  • Screwdrivers & Related

  • Pry Bar
  • Flat Blade Screwdriver

  • Sockets - Metric

  • 19mm Socket
  • 21mm Socket
  • 13mm Socket
  • 18mm Socket

Customer Q&A
Ask a question to 1A Auto customers who purchased the product
No questions have been asked about this item.

Fits the following Makes:

Year Make Model Description
1997-2005Buick Century Buick Century Rear Driver or Passenger Side Rearward Lateral Link
2005-2009Buick LaCrosse Buick LaCrosse Rear Driver or Passenger Side Rearward Lateral Link
1997-2004Buick Regal Buick Regal Rear Driver or Passenger Side Rearward Lateral Link
2000-2013Chevrolet Impala Chevrolet Impala Rear Driver or Passenger Side Rearward Lateral Link
2014-2016Chevrolet Impala Limited Chevrolet Impala Limited Rear Driver or Passenger Side Rearward Lateral Link
2000-2007Chevrolet Monte Carlo Chevrolet Monte Carlo Rear Driver or Passenger Side Rearward Lateral Link
1998-2002Oldsmobile Intrigue Olds Intrigue Rear Driver or Passenger Side Rearward Lateral Link
1997-2008Pontiac Grand Prix Pontiac Grand Prix Rear Driver or Passenger Side Rearward Lateral Link

Part Interchange

Brand Label Part Number
DIY Solutions SUS06620
Dorman - OE Solutions 905-502
Dorman OE Solutions 905-502
MOOG RK660276
MOOG Chassis Products RK660276
Mevotech CMS501006

This item may be interchangeable with parts from other brands with the above part numbers. This information is provided only for reference and does not guarantee that the item you are purchasing is identical to parts with part numbers from the brands listed above. To confirm that this item fits your vehicle, use the above "Check Vehicle Fit" option.
