How To Replace Windshield Wiper Arms 2002-06 Jeep Liberty
Created on: 2014-01-15
How to repair a damaged wiper arm to the Jeep Liberty, years 02, 03, 04, 05, and 06.
-
step 1 :Remove the wiper arm
- Pry off the cap at the base of the wiper arm.
- Use your socket and ratchet to unbolt the 15 mm nut.
- Pull the wiper arm off.
- Disconnect the wiper blade if you plan to transfer them onto the new wiper arms.
-
step 2 :Install the new wiper arm
- Clip the wiper arm down onto the wiper transmission.
- Use your 15 mm socket and ratchet to bolt down the nut to secure the wiper arm.
- Replace the little cap covering the 15 mm nut.
Tools needed
-
Flat Blade Screwdriver
15mm Socket
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the internet. Hi. I'm Don from 1A Auto. I hope this how-to video helps you out, and the next time you need a part for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the wiper arms on this 2006 Jeep Liberty, and we show you on the driver's side but the passenger's side is the same procedure, and the only tools you'll need is a flat blade screwdriver and a 15 millimeter socket and ratchet. Start off by prying off this cap with a flat blade screwdriver. Then, remove the 15 millimeter nut on the wiper arm. After it's removed, push the wiper arm in.
Then pull it out and lift it up, and pull it off the stud, and then to remove the wiper blade, just push the tab. Slide it down and off. Put your wiper blade onto your new wiper arm and just push it up until it clicks. Then, put your wiper arm back down onto the stud, and replace that 15 millimeter nut and tighten it up... and then replace the cap and you're all set.
We hope this video helps you out. Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the internet. Please feel free to call us toll free, 888-844-3393. We're the company that's here for you on the internet and in person.
