How To Replace Throttle Position Sensor 1998-2006 Suzuki XL-7
Created on: 2014-02-14
If the throttle position sensor needs to be replaced, find out how to do this easy repair yourself with this how-to video
-
step 1 :Removing the Throttle Position Sensor
- Push the tab and remove the throttle position sensor harness
- Remove the two Phillips screws from the sensor
- Remove the sensor
-
step 2 :Installing the Throttle Position Sensor
- Insert the throttle position sensor into place
- Insert and tighten the two Phillips head screws
- Connect the throttle position sensor harness
Tools needed
-
Phillips Bit in a Ratchet
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and the next time you need a part for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the throttle position sensor on this 2002 Suzuki XL-7. The tool that you're going to need for this is a Phillips bit and a ratchet. Your throttle position sensor is located right here. Just push the tab on the harness and pull it free.
Then you want to remove these two Phillips screws. We'll just fast-forward as Don does this. Once those are removed, the sensor will pull right off.
Take your new throttle position sensor, push it into place, and replace those two Phillips screws. We'll fast-forward as he replaces both of them and tightens them up. Then reconnect your harness and you're all set.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
