How to Replace Sun Visor 2014-19 Chevy Silverado
Created on: 2019-05-03
Watch this 1A Auto video to learn how to remove and replace a worn, damaged, or broken sun visor on your 14-19 Chevy Silverado.
-
step 1 :Removing the Sun Visor
- The following applies for either side
- Pry off the trim piece where the visor mounts to the vehicle
- Remove the three T15 Torx screws to remove the visor
- If the visor has a mirror and light, remove the electrical connector
-
step 2 :Installing the Sun Visor
- The following applies for either side
- Reconnect the electrical connector, if applicable
- Replace the visor with the three T15 Torx Screws
- Replace the trim piece
Tools needed
-
Flat Blade Screwdriver
T15 Torx Driver
Ratchet
What's up, guys? I'm Andy from 1A Auto. In this video, I'm going to show you how to replace the sun visor on this 2015 Chevy Silverado. If you need parts for your vehicle, click the link in the description and head over to 1aauto.com.
Just grab the front, pull that out like that, and slide it away. Just going to take a pocket screwdriver and get under this trim piece right here. Unlatch it. Some clips that hold it on. Slide that off there and then you can slide that out.
There's three screws in here. We're going to remove those three screws with a T15, on an extension in a ratchet. All right, I know when I'm taking the last one out, I'm going to fold the visor so it doesn't fall. And slide that out.
Now, if your visor had a mirror here with a light on it, then you would have a connector with some wires on it. You'd have to disconnect the connector, but this one does not have that. And now, we can do the same with the other side.
Now take this visor and get this lined up in position. Sometimes it's easier to click it in, but I'm going to start the screw first. Just take a T15 and an extension and the screw. Get one of those started. Grab another one--get this started.
All right, once those are all started, then we can just take the ratchet and snug them up. We can move this, in this position, take this little trim piece. It's going to go over that. And then you click in place. You can lock it in. Now, I'm going to do the same with the other side.
Thanks for watching. Visit 1aauto.com for quality auto parts shipped to your door. The place for DIY auto repair. And if you enjoyed this video, please click the subscribe button.
