How to Replace Power Window Switch 2001-04 Chrysler Sebring
Created on: 2013-10-25
How to repair, install, fix, change or replace a damaged, worn out, faulty or shorted power window switch on 01, 02, 03, 04 Chrysler Sebring.
-
step 1 :Removing the Door Panel
- Pry off the trim piece inside the door handle with a flat blade screwdriver
- Pry off the trim piece inside the door pull with a flat blade screwdriver
- Remove the Phillips head screw inside the door handle
- Remove the Phillips head screw inside the door pull
- Remove the four Phillips screws around the edge of the door panel
- Pry off the mirror base trim piece with a flat blade screwdriver
- Pry out the door panel by hand
- Lift the door panel up and off
- Unclip the door latch rod from the door handle
- Disconnect the door lock wiring harness
- Disconnect the window switch wiring harness
-
step 2 :Removing the Window Switch
- Remove the three T20 Torx screws from the back of the window switch
- Pull off the window switch
-
step 3 :Installing the Window Switch
- Push the window switch into place
- Insert the three T20 Torx screws into the window switch
-
step 4 :Installing the Door Panel
- Clip the latch rod into the door handle
- Connect the door lock wiring harness
- Connect the window switch wiring harnesses
- Lift the door panel into place
- Push in the door panel clips
- Insert the Phillips screw into the door pull
- Insert the Phillips screw into the door handle
- Insert the four Phillips screws around the edge of the door panel
- Push on the trim piece inside the door handle
- Push on the trim piece inside the door pull
- Push on the mirror base trim piece
Tools needed
-
Flat Blade Screwdriver
Phillips Head Screwdriver
T20 Driver
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we show you how to replace the power window switch panel on this 2004 Chrysler Sebring 4-door sedan. It's the same process on these 4-door sedans from 2001 to 2004. We'll be using a new panel, the switch panel from 1AAuto.com, flat blade screwdriver, Phillips screwdriver, and a T20 Torx driver.
There are two trap doors here. There's one right here behind the door handle and another one here in the pull cup. All you want to do is take a flat blade screwdriver and stick it into the slot on the side of them and just pry them out. Now what you want to do is remove each of these Phillips screws. There are six in total. Just speed up the tape here as we remove those screws. Take your flat blade screwdriver and pry off that triangle panel. To release the clips on the back of the door panel you just want to pull out all the way around the door panel. Once you've done that you can lift it up and off of your door lock knob. In behind the back of the door panel you'll see here's your door handle rod. You just want to pop that clip up and pull that up and out. You want to disconnect the two harnesses here by just pushing in the tab and pulling them out. Now your door panel is free.
You'll see there are three T20 Torx screws that actually secure it to the door panel. Once the screws are removed it just pulls right out. Now to install your new switch panel from 1A Auto you just push it into place and replace those three T20 Torx screws. We're just going to fast forward as Don replaces these.
To reinstall the door panel you just want to take that door handle rod, put it back into place, and reclip it. Then you want to just reconnect your two harnesses. Once you've done that you want to just line up your door, put it up and over the door lock knob, and down into place. Then you just want to push those clips in around the edges of the door panel. Again, speed things up as we put those six screws back in. Now just replace your trap doors and that triangular panel.
