How To Replace Power Mirror Switch 2004-07 Jeep Liberty
Created on: 2014-01-16
How to repair, install, fix, change or replace a damaged, worn out, faulty or shorted power window switch on Jeep Liberty, years 04, 05, 06, and 07.
-
step 1 :Removing the Door Panel
- Pry off the trim piece inside the door handle with a flat blade screwdriver
- Remove the Phillips head screw inside the door pull
- Remove the Phillips head screw inside the door handle
- Pry out the door panel with a door panel clip tool or putty knife
- Lift the door panel up and off
- Disconnect the door handle rod from the door handle
-
step 2 :Removing the Switch Panel
- Pry out the tabs on either side of the switch with a flat blade screwdriver
-
step 3 :Installing the Switch Panel
- Snap the new switch panel into place
-
step 4 :Reinstalling the Door Panel
- Connect the lock rod to the door handle
- Lift the door panel into place
- Push in the door panel clips
- Insert the Phillips head screw inside the door handle
- Insert the Phillips head screw inside the door pull
- Push on the trim piece inside the door handle
Tools needed
-
Flat Blade Screwdriver
Phillips Head Screwdriver
Putty Knife
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and the next time you need a part for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the power mirror switch on this 2006 Jeep Liberty. It's the same part and process on these vehicles from 2004 to 2007. The items you'll need for this include a new power mirror switch from 1AAuto.com, a flat blade screwdriver, and a Phillips screwdriver.
Start off by prying out this little panel behind your door handle. Now remove this Phillips screw and this one down in your pull cup. We'll just fast-forward as Don does this. Now pull out around the door panel to release the clips. When you get to the top, pry the door panel out. Once the clip pops free, pull the door panel up and off.
On the back of your door panel, you want to release the clip on your door handle rod and pull the door handle rod down and out. Then you want to push the tabs on both harnesses and release them. Using your flat blade screwdriver, just pry out the tabs on either side of the switch, and it pops right out.
On the left is the old power mirror switch; on the right is the new one from 1A Auto. You can see they're identical, and will mount exactly the same. Just push your new one into place.
Now, to replace your door panel, push the harnesses back into place. Push the door handle rod back into place and re-clip it. Then line your door panel up and push it down onto the windowsill and over that lock. Now make sure your clips are lined up and hit them in around the door panel. We'll just fast-forward here as Don replaces those two Phillips screws and replaces that little panel behind the door handle.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
