How to Replace Heater Blower Motor with Fan Cage 1994-2004 Ford Mustang
Created on: 2011-12-28
How to repair, install, fix, change or replace a broken, weak, noisy or screeching heater and air conditioning fan blower motor on Ford Mustang, years 94, 95, 96, 97, 98, 99, 00, 01, 02, 03, or 04.
-
step 1 :Removing the Blower Motor
- Unclip the blower motor wiring harness from the blower motor cover
- Remove the three 8mm bolts from the blower motor
- Pull down the blower motor
- Pull off the blower motor cover
- Disconnect the blower motor wiring harness
-
step 2 :Installing the Blower Motor
- Connect the blower motor wiring harness
- Put the cover on the blower motor
- Lift the blower motor into place
- Insert the three 8mm bolts into the blower motor
- Clip the wiring harness to the blower motor cover
Tools needed
-
Socket Extensions
8mm Socket
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the fan or the ac or heater blower motor on this 2000 Ford Mustang, same as any 1994 to 2004 Ford Mustang. The only tool you'll need is an 8mm socket with a ratchet and extension. You usually know if your blower motor is going if it's making a loud groaning noise or a high pitched noise that changes with the speed of the fan.
Your blower motor is right in here, underneath and there are three screws: one there, one right over here and one down here. You'll want to take and pull out and down on that connection there, just to pull it loose. I'm going to fast forward just through removing those three, 8mm bolts. Pull it down and then it's connected right here. Pull up on this tab and off.
Your motor from 1A Auto connects just like the original. Put our cover back on and up in there, turn up and in. There's a line up tab right there. Just make sure your wires are coming up out of the case right above here. Go up in, that alignment tab there and now it's in place.
I'll start one of my bolts. I'm going to speed up here again. Start each of those bolts in by hand first, then use your socket, ratchet and extension and tighten them up. You want to tighten them up firm, but don't over tighten them, because you can strip the plastic.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
