How To Replace Door Armrest GMC Savana

Created on: 2021-01-16

Need to replace the door arm rest? This video will show you how to do it quickly and easily

  1. step 1 :Removing the Door Pull
    • Pry off the trim piece on the door pull with a flat blade screwdriver
    • Remove the six Phillips screws from the door pull
    • Pull off the door pull
    • Pry off the door handle bezel with a flat blade screwdriver
  2. step 2 :Installing the Door Pull
    • Push on the door handle bezel
    • Put the door pull into place
    • Insert the six Phillips screws into the door pull
    • Push on the door pull trim piece

Tools needed for replacement

  • Screwdrivers & Related

    Flat Blade Screwdriver

    Phillips Head Screwdriver

Installation Video
Watch video

Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.

Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.

In this video we are going to show you how to replace the door panel pull trim that often breaks on these vehicles. This is a 2005 GMC Savana, pretty much the same for any 2003 to '12 or '13 Savana as well as the Chevy Express. Only tools you will need are a flat blade screwdriver and a Philips screwdriver as well as a new door panel repair kit from 1AAuto.com.

Start with the flat blade screwdriver and pry out on this outer panel and usually this is the panel, that's all broken on most trucks anyways. Now you can remove the inner panel by removing six screws: three small ones there, a larger one there and another small one there and a larger one there. We are just going to fast forward as we remove all those screws and once those screws are out, we might have to pull a little bit, but that panel comes off. We use a flat blade screw driver again and pry on the panel that is right behind the door handle and that comes out.

We have the old one on the left and you can see that the door pull area is broken on the old one. That's, a lot of times, what happen. The new one from 1A Auto is going to fix that problem. You can put the bracket in the back, back on and secure it with the six screws. The two larger screws go in each end, right where you pull on the panel. A little bit of assembly is required. They are just clips that come with the outer trim piece. Press those clips onto the tabs on the inside of the trim panel and we'll just install it like we took it off. Align, and press it in, and set the clips.

We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.

Tools needed for replacement:

    Screwdrivers & Related

  • Flat Blade Screwdriver
  • Phillips Head Screwdriver

2003 - 2014  Chevrolet  Express 1500 Van
2003 - 2014  GMC  Savana 1500 Van
2003 - 2018  Chevrolet  Express 3500 Van
2003 - 2018  Chevrolet  Express 2500 Van
2003 - 2018  GMC  Savana 2500 Van
2003 - 2018  GMC  Savana 3500 Van
2003 - 2014  Chevrolet  Express 2500 Van
2003 - 2014  Chevrolet  Express 3500 Van
2003 - 2014  GMC  Savana 2500 Van
2003 - 2014  GMC  Savana 3500 Van
2003 - 2013  Chevrolet  Express 2500 Van
2003 - 2013  Chevrolet  Express 1500 Van
2003 - 2013  GMC  Savana 2500 Van
2003 - 2013  GMC  Savana 3500 Van
2003 - 2013  Chevrolet  Express 3500 Van
2003 - 2013  GMC  Savana 1500 Van
