How to Replace Transfer Case Shift Motor 2000-02 Chevy Suburban
Created on: 2014-06-10
Watch this video to learn how to fix your four wheel drive if it's stuck or you can't shift into or out of 4wd. The experts at 1A Auto show you how to replace the 4WD transfer case shift motor on your 00-06 Chevy Suburban or Tahoe, or GMC Yukon.
-
step 1 :Removing the Transfer Case Plate
- Remove the four 15mm bolts from the transfer case plate
- Pull off the transfer case plate
-
step 2 :Disconnecting the Driveshaft
- Remove the four 11mm bolts from the driveshaft
- Mark both sides of the driveshaft connection so that you can line it up later
- Pull back the transfer case shift motor cover
- Pull the driveshaft back
- Pull the driveshaft aside
-
step 3 :Removing the Transfer Case Shift Motor
- Disconnect the transfer case shift motor wiring harnesses
- Remove the three 15mm bolts from the shift motor
- Pull the shift motor down and out
-
step 4 :Installing the New Transfer Case Shift Motor
- Remove the plastic cover from the new shift motor
- Remove the gasket from the old shift motor
- Put the gasket onto the new shift motor
- Clean the shift motor mounting area
- Connect the shift motor wiring harnesses
- Turn the ignition on
- Set the shift motor to the setting the transfer case is in with the dashboard button
- Turn the ignition off
- Push the shift motor into place
- Insert the three 15mm bolts into the shift motor
- Tighten the three 15mm bolts to 45 foot-pounds of torque
- Pushing the wiring harnesses into place
-
step 5 :Reconnecting the Driveshaft
- Push the driveshaft into place
- Line up the driveshaft using the marks from Step 2
- Push on the shift motor cover
- Put the driveshaft brackets into place
- Insert the four 11mm bolts into the driveshaft
-
step 6 :Reinstalling the Transfer Case Plate
- Lift the transfer case plate into place
- Insert the four 15mm bolts into the transfer case plate
Tools needed
-
Torque Wrench
15mm Socket
Jack Stands
Ratchet
Cloth Rags
Floor Jack
11mm Socket
Marker / Writing Utensil
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and, please, next time you need parts for your vehicle, think of 1AAuto.com.
In this video, we're going to show you how to replace the transfer case shift motor on this 2002 Chevy Suburban. It's the same part and similar process on these Suburbans from 2000 to 2002. The items you'll need for this are a new transfer case shift motor from 1AAuto.com, 15mm socket and ratchet, 11mm wrench, a marker and jack and jack stands.
Start off by removing these four 15mm bolts, and we'll just fast forward as Mike does this. Once those are removed that pan will pull forward, and then you want to come up here and remove these four 11mm bolts. We'll fast forward as Mike uses an 11mm wrench and an extra wrench to give him some added leverage. Mark right here and right here, so you can line these up again the same way when you put it back, and then up by your transfer case shift motor just pull back this cover, and then you want to just pull the driveshaft out and then lift it up. It should pull out, and then just push this side toward the outside of the vehicle.
Pull up on the tab on the harness and disconnect it, and then pull this other harness just up and out. It's easiest to use a flat blade screwdriver and just pry down on the tab and disconnect the harness. Then, remove these three 15mm bolts. Now, you can pull the transfer case shift motor back, and then, down and out.
On the left, is the old transfer case shift motor; on the right, is the new one from 1A Auto. You can see they're identical and they'll fit exactly the same. Remove this plastic cover and then you just want to pull this gasket off your old transfer case shift motor and transfer it over to your new one. Wipe down the area where your transfer case shift motor goes, and then reconnect the two harnesses for your transfer case shift motor. Then you just kind of set the motor up there.
You'll want to put your new motor in the same position as the truck was when you took it apart. In this case, ours was in 2 Hi, so we select the 2 Hi button, shut the key off and you can hear the motor switch, and then turn the key back on and it will indicate that it's now in 2 Hi, and so we can proceed. You should be able to push it into place. Now replace those three 15mm bolts and tighten them up. You want to torque those to about 45 foot-pounds. Now, push that harness back into place, and then, push your driveshaft back into place, and set it back in, making sure those dots line up that you marked earlier. Then, push this cover back into place and replace those two 11mm bolts on the bottom and the two 11mm bolts on the top, along with those brackets that they hold in place. We'll just fast forward as Mike does this.
Now, you just want to put that plate back up into place and replace and tighten up those 15mm bolts. Once you've done that, you're all set.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
