How To Replace Tailgate Linkage Rods Ford 1992-96 F-150 F-250 F-350

Created on: 2012-12-25

If the tailgate linkage rods are bent, corroded, or broken, this video will show how to remove the tailgate bed to access and replace them

  1. step 1 :Removing the Bed Liner
    • This step is not necessary if you do not have a bed liner
    • Open the tailgate, if possible
    • Remove the Phillips screws from the bed liner
    • Pull off the bed liner
  2. step 2 :Removing the Tailgate Latch Rod
    • Remove the four T30 Torx screws from the access panel
    • Pull off the access panel
    • If the tailgate was stuck closed, press in the latch mechanism to open the tailgate
    • Pry off the latch rod clip with a flat blade screwdriver
    • Pull the latch rod off the latch mechanism
    • Pull the clip out of the tailgate with pliers
    • Remove the two T45 bolts from the tailgate cable bracket
    • Pull off the tailgate cable bracket
    • Pull out the latch rod
    • Unclip the latch rod from the bracket
  3. step 3 :Installing the Tailgate Latch Rod
    • Clip the latch rod onto the bracket
    • Push the bracket into place
    • Insert the two T45 bolts into the bracket
    • Clip the latch rod to the tailgate
    • Clip the latch rod to the latch mechanism
    • Apply rust penetrant to the latch mechanism
    • Apply white grease to the latch mechanism
    • Put the access panel into place
    • Insert the T45 Torx bolts into the access panel
  4. step 4 :Installing the Bed Liner
    • This step is not necessary if you do not have a bed liner
    • Put the bed liner into place
    • Insert the Phillips screws into the bedliner
    • Close the tailgate

Tools needed

  • Flat Blade Screwdriver

    Phillips Head Screwdriver

    T30 Bit

    Rust Penetrant

    White Grease

    T45 Socket

    Slip-Joint Pliers

    Ratchet

Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.

Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.

In this video, we're going to show you how to replace the tailgate handle and latch connecting rods on this '96 Ford F150, pretty much the same for any '87 to '96 F150, 250, or 350 and a very similar procedure for pretty much almost any Ford truck that uses this style of rod. The tools you'll need are a Phillips screw driver. There's a couple of stars there because I use a Phillips screw driver on this truck due to the fact that it has a bed liner and that's the screws they use. This could differ if you have a different type of bed liner. You'll need T30 and T45 Torx bits with ratchets, flat blade screw driver, pliers, and some penetrating oil and white grease to lube up the mechanisms when you're done.

Start by opening your tailgate, if you can. If your handle and mechanism is broken in a way that the tailgate won't open, that's okay. You can just do these steps from the inside. This truck has a bed liner on it, so I'm using a Phillips screw driver to remove the screws that are holding the bed liner to the tailgate. Some of these screws could be on there quite tough so you can see me bearing down quite a bit on some of them. Once I get those off, I slip the bed liner off, and then there are four Torx screws still holding the access panel onto the bed. If you don't have a bed liner, you'll simply just have more of these screws holding the access panel on. Those screws are T30 Torx head screws. You'll need and I'd recommend a T30 Torx bit that you can put on to a ratchet handle.

If you were unable to get your tailgate down before, once you have the access panel off, you can either squeeze the mechanism or pull on each individual rod. Pull each rod in towards the center of the truck and that should release your tailgate. Once you have that panel off, see right back here is the back of your handle, these yellow clips. I'm just going to show you one side, but obviously you'd want to undo them both with a flat blade screw driver. Just pry right up underneath. Then lift the rod right up and out. Now take a pair of pliers. It's just a little clip here. Squeeze the clip. Then push it down through the hole. Do that again. Squeeze both sides of the clip. Push it down a little bit, down through the hole.

Now the rod is connected here, so you'll need to remove these two T45 bolts. I've got a T45 Torx driver. You want to be careful as you're removing this one because it holds the tailgate cable. Make sure your other tailgate cable is in good order or you're supporting the tailgate. If you take the tailgate cable off and the other one is broken or something, your tailgate can fall and get dented. Get your cable off. Pull this clip out. Then the rod just twists right out and comes off.

My rod is in fine shape, so I'm just going to reinstall it. To install the new one from 1A Auto, put it in, twist it around. Put this rod in. Make sure that as you're putting the rod in, you get it in this area. Make sure it doesn't go down in behind there. Guide the rod from the back side. Pull it right in. Start that. Start that. Make sure, as you're tightening this up, that your tailgate cable is nice and loose. Then after you tighten it, the tailgate cable should be nice and free. Now this little clip that goes in here, just spread out. Clip it on to your rod and then, lifting up the yellow clip over here, put the rod in place. Then I'll get this clip here in place first and pull it up through. That clip is in place. Then I want to just pull on the rod a little bit. Just put some tension on it and then push it down into its place. Then lock the yellow clips down. You need this screwdriver. Make sure it clips on there correctly. It would be a good idea while you're in here and have this opened up to take some penetrating oil, spray all your mechanisms. Then follow this up with a good coat of white grease. I'll speed up here again as I put the access plate back on.

Again, my truck has a bed liner, so I put it on. Put the four T30 Torx screws in first. Tighten those up. Then slip the bed liner cover over it and put the Phillips screws in and again, depending on your bed liner, some of this hardware may be a little bit different, but it should be basically the same, the same idea.

We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
