How To Replace Side Rear View Mirror 1995-2005 Chevy Cavalier
Created on: 2013-08-27
How to repair, install, fix, change or replace a broken, smashed, cracked, or shattered side view mirror on Chevy Cavalier, model years 96, 97, 98, 99, 00, 01, 02, 03, 04, and 05.
-
step 1 :Removing the Side Rear View Mirror
- Remove the Phillips screw from the base mirror piece
- Remove the base mirror piece
- Remove the insulation behind the panel
- Remove the three 10mm nuts on the base of the mirror
- Pull the mirror out
- Peel the insulation off if it does not remove with the assembly
-
step 2 :Installing the New Side Rear View Mirror
- Push the mirror into place
- Insert and tighten the three 10mm nuts
- Insert the insulation
- Push in the base mirror piece
- Insert and tighten the Phillips screw to the base mirror piece
- Test the mirror in all four directions
Tools needed
-
Phillips Head Screwdriver
10mm Wrench
10mm Socket
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and the next time you need a part for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the driver side mirror on a 2000 Chevy Cavalier. It's a very similar operation for many years of the Cavalier, as well as for the passenger side. You'll need a new mirror assembly from 1A Auto as well as a 10mm socket and socket wrench, a 10mm open-ended wrench, and as a Phillips head screwdriver.
Locate the Phillips head screw that's in the cover by the handle. I'm removing that screw with the Phillips head screwdriver and pulling that panel off. Pull out the insulation that's in the little area there behind the panel. Locate the three 10mm nuts. Fast-forward as I remove two of those nuts with the socket and socket wrench. The third one closest to the front of the door is tough to get to with the socket wrench, so I'm using an open-ended wrench. Fast-forward as I take that out. Pull the mirror away from the door and out.
If the insulation doesn't come off with the mirror assembly, you'll need to peel it off the door itself. Here's a side-by-side comparison of the old part and the new part. They're identical.
With the new mirror, I'm just going to make sure that the handle goes through the hole there. Push it up and try to keep it from falling out for a second while you open the door and get in to start putting in those three 10mm nuts. Then fast-forward as I finish putting in those three nuts.
Reinstall the insulation or the little foam padding and the triangular piece that you took out from the inside of the door. Now reinstall the triangular cover panel with the Phillips head screw. Check to make sure that it's fully operational in all four directions.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
