How to Replace Side Marker Light 1995-2000 Chevy Tahoe
Created on: 2014-03-04
How to repair, install, fix, change or replace a broken, damaged, cracked, faded, cloudy, or chipped signal light on 96, 97, 98, 99, Chevy Tahoe, Suburban, C1500 or K1500 trucks.
-
step 1 :Removing the Side Marker Light
- Remove the four Phillips screws from the parking light bracket
- Twist the bulb socket counterclockwise out of the light
- Remove the two 13mm nuts from the side marker light
- Twist the bulb socket counterclockwise out of the light
- Pull the side marker light out
-
step 2 :Servicing the Bulbs
- Twist the bulb socket counterclockwise out of the light
- Pull the bulb off of the socket
- Push on the new bulb
- Twist the bulb clockwise into the light
-
step 3 :Installing the Side Marker Light
- Insert the side marker light into place
- Replace the two 13mm nuts
- Twist the bulb clockwise into the light
- Line up the bolt holes on the side marker light bracket to the bolt holes on the vehicle
- Replace the four Phillips screws into the parking light bracket
Tools needed
-
13mm Socket
Phillips Head Screwdriver
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace as well as service the bulb in a side marker light on this 1996 Chevy Tahoe. We show you in the passenger side, but the driver side is the same procedure. The items you'll need for this include a new side marker light from 1AAuto.com, a Phillips screwdriver and a 13mm socket and ratchet.
Start off by removing these four Phillips screws. We'll just fast-forward as Don does this. Once those removed, pull the light out, and you just twist the sockets counterclockwise to remove them.
Now to service the bulb on your side marker light. You just twist the socket out and the bulb pulls straight out. You push your new one in, and then the socket twist back into the side marker light.
To change the assembly, you want to remove these two 13mm nuts, so just twist out that socket and remove those two nuts. We'll just fast-forward here as Don does this. Once those are removed, the side marker light will pull right out.
On the left is the old side marker light; on the right is the new one from 1A Auto. You can see they're identical, and they'll mount exactly the same.
Push your new side marker light into place and replace those two 13mm nuts. Then twist your socket back into place.
Now take your parking light and twist those two parking light sockets into place by just twisting them clockwise to lock them. Then push your parking light assembly into place. Make sure all four of those holes line up, and replace those four Phillips screws. Then you're all set.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
