How to Replace Seat Switch 2001-07 Chevy Silverado
Created on: 2014-06-17
Find out how to replace a broken or faulty power seat switch with the simple steps in this how-to video
-
step 1 :Removing the Seat Switch
- Remove the four Phillips head screws from the seat switch panel
- Pull the panel off of the seat
- Disconnect the seat switch wiring harnesses
- Remove the three 7mm bolts that hold the switch to the switch panel
-
step 2 :Installing the New Seat Switch
- Push the new switch into the panel
- Insert the three 7mm bolts into the switch
- Connect the seat switch wiring harnesses
Tools needed
-
Flat Blade Screwdriver
Phillips Head Screwdriver
7mm Socket
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the seat switch on this 2002 Chevy Suburban. On this particular vehicle, it's the twelve-way seat switch, but the regular seat switches use a similar procedure. The tools you'll need for this are a 7mm socket and ratchet, a Phillips screwdriver, and a flat blade screwdriver.
Start off by removing these four Phillips screws. We'll just fast forward as Don does that. Now just pull straight out on this panel. Then you want to just pry down on this tab and pull the harness free. For this harness, you want to just push down on the tab and disconnect it. Now remove these three 7mm bolts. Now the switch will just pull right out.
Take your new switch and push it into place, and then replace those three 7mm bolts. Reconnect the two harnesses. Now push the seat switches back into place, and then replace those four Phillips screws.
