How to Replace Rear Window Switch 2005-16 Toyota RAV4
Created on: 2019-09-12
Learn how to replace the window switch quickly and easily with this how-to video
-
step 1 :Removing the Rear Window Switch
- Pry up the switch with a trim tool
- Disconnect the wiring harness
- Pry out the switch with a flat blade screwdriver
-
step 2 :Installing the Rear Window Switch
- Press the switch to the trim
- Connect the wiring harness
- Press the switch into the door panel
Tools needed
-
Flat Blade Screwdriver
Trim Tool Set
What's up guys? I'm Andy from 1A Auto. In this video, I'm going to show you how to replace the rear window switch on this 2010 Toyota RAV4. If you need parts for your vehicle, click the link in the description and head over to 1AAuto.com
I'm going to take a trim tool, and I want to get underneath this bezel right here. Slide this up, slide this out of the way and then disconnect the connector right here. Just push down, disconnect the connector. Just take a pocket screwdriver. There's some tabs right here. You can try to push them from right there, but sometimes it's a little easier to go in between the two panels to release it right there. Put a little pressure from the front side and just rock it out just like that.
Take the switch. You want to line the switch up like this, so the switch part is towards the front of the bezel. Slip it over, line it up, lock it in place. Reconnect the window switch to the connector, line it up, lock it in place. Then there's a slide right here that slides in the back, that slides like that, and then push down on the front.
Thanks for watching. Visit 1AAuto.com, your place for DIY auto repairs, for great parts, great service, and more content.
