How to Replace Outer Tie Rods 2007-16 GMC Acadia

Share on:

Created on: 2020-08-12

This video shows you how to install a new outer tie rod on your 2007-16 GMC Acadia.

Now, you can take the lug nuts off. Use the 22-millimeter socket, so you can get the wheel off. Grab the wheel, slide it off. I'm gonna loosen up the jam nut. Just take a 15/16 wrench and loosen it up. That's good. I'm just gonna take a little rust penetrant, just spray down the tie rod stud. That'll make it a little easier to take that nut off. I'm just gonna take a pry bar, and just pry below the strut, and prying down on the tie rod to help the stud from spinning. And then use a 21-millimeter socket, take that nut off. Now, just take a hammer and hit on the bottom of the stud, going up. When you take this off, you're gonna want to count the threads, so, 1, 2, 3...17, 17, and just write that number down somewhere.

That's gonna make it easier for when you put it back together to get it close so that when you go to have the alignment done, it's actually a little bit closer than if you didn't count the threads. Now, take the outer tie rod end and count the threads when you go on. 1, 2...17. And I'll just move the jam nut a little closer and take the stud and line it up with the nut hole.

Take the nut, put the nut on. Now I'll take a pry bar, go under the strut, slide this down. And then I'm gonna torque this nut to 22 foot-pounds. And if you have angle meter, you're gonna want to torque this an additional 120 degrees. If you don't, just do the best you can. That's 90, then I'll go another 30 degrees. I'm just estimating; that's about right. And we can tighten up the jam nut. If you have the ability to torque this, you can torque it to 55 foot-pounds. Now, put the wheel back on.

Now I'm gonna tighten the lug nuts down, torque them to 140 foot-pounds in a cross pattern so that it tightens the wheel down evenly. Go around again. Double check.

2007 - 2010  Saturn  Outlook
2007 - 2016  GMC  Acadia
2009 - 2017  Chevrolet  Traverse
2008 - 2017  Buick  Enclave
2017 - 2017  GMC  Acadia Limited
2008 - 2012  Buick  Enclave
2007 - 2012  GMC  Acadia
2009 - 2012  Chevrolet  Traverse
2013 - 2016  GMC  Acadia
2013 - 2017  Chevrolet  Traverse
2013 - 2017  Buick  Enclave
