How to Replace Master Power Window Switch 1993-97 Toyota Corolla
Created on: 2011-09-30
How to repair, install, fix, change or replace a damaged, worn out, faulty or shorted power window switch on Toyota Corolla, years 93, 94, 95, and 96.
-
step 1 :Removing the Window Switch
- Pry up the window switch panel with a flat blade screwdriver
- Disconnect the window switch wiring harness
- Remove the three Phillips head screws that hold the switch to the switch panel
- Pry the switch out of the switch panel
-
step 2 :Installing the Window Switch
- Push the window switch into the switch panel
- Insert the three Phillips screws that hold the switch to the panel
- Connect the window switch wiring harness
- Push the switch panel into the door panel
Tools needed
-
Flat Blade Screwdriver
Phillips Head Screwdriver
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
In this video, we are going to show you how to replace the master window switch. Sometimes if your windows stop working, it can be the lock-out button on the master's window switch goes bad. The only tools you'll need . it's pretty easy . you'll need a flat blade screw driver and a Phillips screwdriver.
Take a screwdriver, simply go up and underneath, pry it out gently, and pull this forward. Pull this out. There's a button right underneath here. Press the button on the plug. Now, there should be three Phillips screws here, but it would appear that I'm missing a couple there. Then, carefully, there are tabs on each side; pull back the tab. Pull out on the switch at the same time.
Do the same thing on the other side. Obviously, somebody's probably done this before. The switch comes out; reinstall. The switch goes down in. Click it into place. Start my one screw up here and I just went and found a couple of screws for the back here. Reconnect back in first. Press the button down here.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
