How to Replace Ignition Coil 2001-06 Chrysler Sebring 2-7l
Created on: 2013-10-24
Watch this how-to video and learn how to do this simple repair yourself
-
step 1 :Removing the Ignition Coil
- Disconnect the ignition coil wiring harness
- Remove the two 8mm bolts from the ignition coil
- Pull the ignition coil up and out
-
step 2 :Installing the New Ignition Coil
- Push the new ignition coil into place
- Insert the two 8mm bolts into the ignition coil
- Connect the ignition coil wiring harness
Tools needed
-
8mm Socket
Ratchet
8mm Wrench
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace an ignition coil in a 2004 Chrysler Sebring sedan. It's got the 2.7 liter V6 engine. For this repair you'll need a new ignition coil from 1A Auto as well as an 8mm socket and ratchet. Here's an engine cylinder diagram for the 2.7 liter V6, so if you have an engine code for a cylinder number two or cylinder number five misfire, that very well could be a bad coil. In this video we're going to be doing cylinder number two.
Go ahead and locate your ignition coil packs. That's two, four, and six. On the backside it's one, three, and five on the end right there. We're going to be doing ignition coil number two. We're going to first push down on the tab for the connector and pull that free, set it aside. Then take your 8mm socket and ratchet and start to unscrew the two screws that hold it in place. I'll fast foward as I do that. Now with those screws out you can go ahead and pull out your ignition coil.
We're replacing the coil with a new coil from 1A Auto. You can see it goes right in. Use the same screws to fasten it down. Put them in by hand first and tighten them up. After that just reconnect. All the other coils are the exact same and the rear ones are just a little bit tougher to get to. You may have to use a 10mm wrench rather than a socket and ratchet.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
