How to Replace Front Door Tweeter Speaker 2005-16 Toyota RAV4
Created on: 2019-09-19
Check out this video to learn how to replace the tweeter speaker in your 05-16 Toyota RAV4. 1A Auto shows you how to DIY it!
-
step 1 :Removing the Front Door Panel
- Pry off the sail panel behind the mirror
- Pry up underneath the window switch bezel
- Disconnect the window switch connector
- Pry out the trim piece behind the door handle
- Pry off the trim bezel from the door pull
- Remove the Phillips screw from the door handle
- Remove the two Phillips screw from the door pull
- Pry out the door panel from its clips with a trim tool
- Lift the door panel up and off
- Unclip the door handle
-
step 2 :Removing the Tweeter Speaker
- Remove the two 10 mm speaker bracket bolts
- Disconnect the speaker electrical connector
-
step 3 :Installing the Tweeter Speaker
- Connect the speaker electrical connector
- Secure the speaker bracket with the two 10 mm bolts
-
step 4 :Installing the Front Door Panel
- Clip on the door handle
- Lift the door panel up into place
- Press in the door panel clips
- Tighten the two Phillips screws to the door pull
- Tighten the Phillips screw to the interior door handle
- Press on the interior door handle trim
- Press on the door pull trim
- Connect the window switch wiring harness
- Press the window switch into the door panel
- Press the sail panel behind the mirror into the door
Tools needed
-
Socket Extensions
Flat Blade Screwdriver
10mm Socket
Ratchet
Trim Tool Set
What's up guys? I'm Andy from 1A Auto. In this video I'm going to show you how to replace the front door tweeter speaker on this 2010 Toyota RAV4. If you need parts for your vehicle, click the link in the description and head over to 1AAuto.com.
We're going to take a trim tool and just get underneath this trim right here, slide it out, there's a little clip. I'm going to take this piece off right here, this little trim cover, goes under here, just use the trim tool. Grab that. There's clips that hold that in. Clips right there on top and bottom, and on the front. I want to take this cover off, just use the trim tool in here, just get under there, pry that out. There's clips that hold that in. Two right there, clip there, there, there, and there.
Take the trim tool, go in right behind here, slide up. This slides right out. There's clips right there, clip right there, on the sides, and this just makes it easier to disconnect this connector rather than leaving this connected. So there's a little lock right there, push down on that lock. If you take a trim tool, get it in right here or right here. You can't pull on the wires because it's separate from the connector. Here we go. It slides up like that, and then you can disconnect the connector.
Now there's three Phillips head screws right there. I'm just going to use a Phillips head screwdriver, take these out. We have to use a magnet to get them out. Take that one out. I'm going to take a trim tool, go around the door panel, some clips. Just twist to the side a little bit. Just grab the door panel, slide it up slightly, slip it out. There you go. Comes off nice and easy.
I'm going to use a 10 millimeter socket extension and a ratchet. I'm going to take these two bolts out right here. You could probably use a Phillips head screwdriver, but it's going to be a little bit difficult. Or not, actually, it's not on there too tight. Take this screw out and the same with this one. Pull the speaker out and there's a little lock right there on the connector. Push down on the lock. I need a pocket screwdriver. Get in here, push down on that, slide it out, and there's the tweeter.
Take the speaker, line up the connector. It is slotted, it only goes one way. Lock it in place. Take the screws, get those started and take a 10 millimeter socket or a Phillips head screwdriver and a ratchet. Tighten these up just snug. There you go.
Now we'll take this door panel. We want to slide the wiring harness through there and then take the handle, slide the handle through there. Get that in position. That looks good. Now we're going to slide the panel from up top near the window, get that lined up first. Once that's lined up, just check to see if these pins are lined up with the holes. When they are, just give it a little tap. Go all the way around like that and just feel and make sure the panel is flush with the door and it looks good.
Now I'm going to take these screws. The longer ones are going to go in where the handle is, right there, and use a Phillips head screwdriver. Tighten that up. And this one's going to go right here where the handle is, the door handle. We're going to put this cover on first. It doesn't really matter which order you put them on. Lock that in place. Put this cover on right here, lock it in place. Take the window switch, we're going to line up the connector, push that in, and then push down that little lock down. Position this, right here first, and then push down on the front, just like that. And then take this little cover, just line this up, lock it in place.
Thanks for watching. Visit 1AAuto.com for quality auto parts shipped to your door, the place for DIY auto repair. And if you enjoyed this video, please click the subscribe button.
