How to Replace Front ABS Sensor 2005-10 Chrysler 300
Created on: 2017-01-23
This video shows how to remove and install the wheel and the ABS sensor. Follow our expert's steps and learn how to do it yourself
-
step 1 :Removing the Wheel
- Loosen the lug nuts with the vehicle on the ground
- Raise the vehicle with a floor jack
- Secure the vehicle on jack stands
- Remove the lug nuts
- Pull off the wheel
-
step 2 :Removing the ABS Sensor
- Remove the 10mm nut from the ABS sensor
- Pry out the sensor with a pair of pliers
- Disconnect the harness from its retainers
- Remove the electrical connector at the front of the wheel well
-
step 3 :Installing the ABS Sensor
- Reinstall the electrical connector
- Snap the harness into its retainers
- Press the sensor into place
- Tighten the 10mm nut to the sensor
-
step 4 :Reattaching the Wheel
- Slide the wheel into place
- Start the lug nuts by hand
- Tighten the lug nuts preliminarily
- Lower the vehicle to the ground
- Tighten the lug nuts to 110 foot-pounds in a crossing or star pattern
Tools needed
-
Gloves
Socket Extensions
Flat Blade Screwdriver
Torque Wrench
Rust Penetrant
Jack Stands
19mm Socket
10mm Socket
Ratchet
Floor Jack
Needle nose pliers
1/2 Inch Breaker Bar
Hi, I'm Mike from 1AAuto. We've been selling auto parts for over 30 years! We're dedicated to delivering quality auto parts, expert customer service, and fast and free shipping, all backed by our 100% satisfaction guarantee. So visit us at 1AAuto.com, your trusted source for quality auto parts.
In this video we're going to be working with our 2006 Chrysler 300, 3.5-litre V6, rear-wheel drive. We're going to show you how to remove and replace the vehicle's front ABS sensor, as well as the harness.
If you like this video, please click subscribe. We have a ton more information on this and many other vehicles. If you need this part for your car, you can follow the link down in the description over to 1AAuto.com.
Here are the items you'll need for this repair: 10-21mm socket, ratchet, socket extension, ½ breaker bar, torque wrench, flat blade screwdriver, pliers, gloves, rust penetrant, jack and jack stands
Using a 21mm socket and a breaker bar, loosen all of your lug nuts about one turn. Raise and support your vehicle. We're using a lift to make it easier to show you what's going on, but this job can easily be done at home with a jack and jack stands. Remove your lug nuts the rest of the way by hand. Remove your wheel and tire.
Now we've turned the spindle here to make it easier to show you guys what's going on, but you shouldn't have to do this in order to remove the part at home. Your ABS sensor is located here on the back of the spindle secured by this 10 mm nut, which we'll remove with our 10 mm socket and ratchet. Grab the sensor with a pair of pliers. Just wiggle it back and forth a few times to make sure that it's freed up. Since we're replacing it, you can go ahead and pull it out with the pliers too. Now we'll disconnect the harness from its two retainers. We'll remove the electrical connector at the front of the wheel well by pushing down on this spring retainer. I'm using a little flat blade screwdriver to make it easier to reach and disconnecting the connector. You can now remove the sensor and harness from the vehicle.
Here we have our old ABS sensor that we removed from our vehicle and our new part from 1AAuto.com. As you can see these parts are exactly the same. A little hard to tell, but they are the same length just because this one has settled from being in the vehicle for so long. I'll just grab those and show you they're the same real quick. Now the new harness does come with the actual mounting tabs. Ours didn't break off, so we can simply pop them out of there and snap them right back into the ones we left in the car. Your ABS sensor is prone to getting stuck in the hub and can become broken or damaged, as well as having the wire chafed through from an oversized wheel and tire rubbing up against it. If your old ABS sensor has gone bad or broken, this new part from 1A Auto is going to go in direct fit just like your original equipment. We'll fix you up right.
Reinstall the electrical connector until it snaps. Make sure that it's in there nice and secure. Snap these little rubber knobs here on the harness into their connectors. It will be the same as the ones you removed them from. Install the sensor back into the hub. Start your 10mm bolt. We'll then tighten down with our 10mm socket and ratchet. This is just holding the plastic sensor in so you really only have to snug it up. There's no need to get crazy tight with these.
Reinstall your wheel and tire and get your 21mm lug nuts as tight as you can by hand. Lower the partial weight of your vehicle back on to the tires. Torque your lug nuts to 110 foot-pounds in a cross pattern.
Thanks for watching. Visit us at 1AAuto.com for quality auto parts, fast and free shipping, and the best customer service in the industry.
