How to Replace Fix Door Lock Switch 2005-10 Pontiac G6
Created on: 2013-07-15
If your Pontiac G6 needs a new power window switch, check out this video! 1A Auto shows you how to replace it yourself!
-
step 1 :Removing the Door Lock Switch
- Pry off the trim piece inside the door handle with a flat blade screwdriver
- Remove the T30 Torx screw inside the door handle
- Pull out the door handle
- Disconnect the latch cable from the door handle
- Disconnect the door lock wiring harness
- Press the door lock switch out of the door handle
-
step 2 :Installing the Door Lock Switch
- Press the door lock button into the door handle
- Connect the door lock wiring harness
- Connect the latch cable to the door handle
- Push in the door handle
- Insert the T30 Torx screw inside the door handle
- Press on the trim piece inside the door handle
Tools needed
-
Flat Blade Screwdriver
T30 Bit
Ratchet
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the lock and unlock button on the driver's side of a 2007 Pontiac G6, basically the same for model years 2005-2010. You'll need a new lock switch from 1A Auto, a Torx 30 driver, and a pocket screwdriver.
Use a pocket screwdriver and pull open that cover. Using a Torx 30 socket and extension and a socket wrench, remove the Torx 30 screw that goes through the door handle assembly. Pull out your door handle assembly, and then use a pocket screwdriver to pop off the cable. Use the pocket screwdriver again to press in on the tab for the harness that goes to the lock and unlock button, and pull that out.
Find the two tabs on either side of the housing that holds the button in and pry them apart gently, and then slide the button out.
Install the switch, and then reinstall the harness that goes to the back of the switch. Then you're going to connect the door lock cable. You're going to do so by putting the end of the cable into the hole, and then pressing the clip back down into the housing there. Then go ahead and slide it back in and line up your screw hole. Reinstall the Torx 30 screw that goes through the door handle and into the door. Then close the little cover that covers it up.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
