How To Replace Distributor Cap and Rotor Ford 92-96 F150250350

Share on:

How To Replace Distributor Cap and Rotor Ford 92-96 F150250350

Created on: 2021-01-16

Follow this video in order to see how to replace the distributor cap and rotor on your 92-96 Ford F150/250/350

  1. step 1 :Removing the Air Intake Hose
    • Loosen the three air intake hose clamps with a flat blade screwdriver
    • Unclip the intake hose from the throttle body, oil breather, and max air flow sensor
    • Pull the intake hose up and out
  2. step 2 :Removing the Distributor Cap
    • Flip the two clasps off the distributor cap
    • Pull the cap up
    • Remove the wires and align them correctly onto the new posts on the cap
  3. step 3 :Removing and Installing the New Rotor
    • Remember the rotor's position
    • Pull it up and off
    • Insert the new rotor
  4. step 4 :Installing the New Distributor Cap
    • Insert the distributor cap onto the distributor
    • Clip the two clasps on the distributor cap
    • Connect the coil wire
    • Start the vehicle to test the distributor
  5. step 5 :Reinstalling the Air Intake Hose
    • Push the intake hose into place
    • Insert the hose into the throttle body, oil breather, and max air flow sensor
    • Tighten the intake hose clamps with a flat blade screwdriver
    • Double check all the harnesses and hoses

Tools needed for replacement

  • Screwdrivers & Related

    Flat Blade Screwdriver

Installation Video
Watch video

Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.

Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.

In this video, we show you how to replace the distributor cap and rotor on this 1996 Ford F-150. This truck has the 5.0 liter V8. This process is the same for both the 5.0 liter V8 and the 5.8 liter V8. The only tool you'll need is a flat blade screwdriver.

Look under the engine from the driver's side. You can see the distributor cap right here. It's the blue plastic. You'll first want to remove this intake tube. It makes it easier if you get it out of the way. Start by loosening a hose clamp right down here. Loosen two more hose clamps here, one down here, then one up under here, then this clamp here. Pull that off. Pull that off and pull this up and off. That comes right off. Now you can see the cap right here. It just has a couple little clasps. One's here. Just take your finger and flip them off. One's in the backside, and you can't really see it. You just feel for it. Flip it off. Then you can pull your cap up.

You can see underneath a little bit. Those contacts are blackened, pretty ugly. The rotor should be replaced as well. What I like to do is, there's a little vent right here. Match that up. Here's my vent on my new cap. I just pull this wire off here, and then I make sure that wire should go on to this post right here. I just pull it right over. Put that wire on that post. Then I just go right in order. Take the wires off, and put them on the new cap. I'm going to do all the ones that come from this side first.

What that'll do is it'll let the cap stay over here. I'm going to skip one. I'm skipping taking this one off. I'll skip this one. Take that one off and put it on there. This one's all the way over here. I'm actually going to take the coil wire off as well. That one's easy. We know that one goes right in the middle, so I'll just take that off, and put it back here. Then I'll take this one off. I know it goes through right to here. Really, all I'm doing is I'm just carefully replacing the wires. Now, once you take these next four off, you're going to have to put the new cap in place. What I'll do is just take this one off first, keep it right there. This one off next, keep it right there. Then pull these two off right where they are.

Remove the old cap and put this cap in place. Put these two kind of on, in place, there. I know that this one goes here and this one here. All the wires are on in the same place. I end up back together. Now, I'm actually going to replace the rotor. The rotor, just kind of note its position. It's pointing basically at the engine oil filler. Just pull the rotor right up and off. Okay, here's our old rotor; here's our new one. The old one's all burnt and scored there, never a good thing for getting the charge through. You can see our old cap; all these contacts have significant scoring on them which makes it more difficult to get spark through there.

New rotor, we'll just push right on. Put the new cap in place. Then just pull the clip right up. You may have to reach around the back here a little bit. Put the other one on. Bring our coil wire right down and on. Okay, we just did a quick startup there to make sure everything was working right. As long as you plug the wires into the same location on the new cap as they were on the old cap, you will be fine. I'm just kind of fast-forwarding through as we put that intake tube back on. Put it back on there. Putting the two tubes to the throttle body in correctly, the one tube that goes down to the oil breather, and then the two max airflow sensors. Make sure they're all on there well. Tighten up the clamps and we should be all set. Put it on there. Tighten up this clamp over here. Reach right over I know you can't see it, but tighten up the one that goes to the oil breather here.

We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.

Tools needed for replacement:

    Screwdrivers & Related

  • Flat Blade Screwdriver
