How to Replace Axle Shift Actuator 95-96 Chevy Tahoe

Share on:

How to Replace Axle Shift Actuator 95-96 Chevy Tahoe

Created on: 2014-03-18

Watch this 1A Auto video to learn how to replace the front axle actuator on your 95-96 Chevy Tahoe with four wheel drive.

  1. step 1 :Removing the Four Wheel Drive Actuator
    • Pull the four wheel drive actuator wiring harness of its bracket
    • Disconnect the wiring harness
    • Pull the wire out of its bracket
    • Twist the actuator loose with an adjustable wrench
    • Twist the actuator out by hand
  2. step 2 :Installing the New Four Wheel Drive Actuator
    • Twist in the new actuator by hand
    • Tighten the actuator with the adjustable wrench
    • Clip the wire back into its bracket
    • Reconnect the actuator wiring harness
    • Clip the harness back into its bracket

Tools needed for replacement

  • Pliers, Cutters & misc Wrenches

    Adjustable Wrench

Installation Video
Watch video

Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.

Hi, I'm Don from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.

In this video, we're going to show you how to replace the four-wheel-drive front axle shift actuator on this '96 Chevy Tahoe. It's the same part and process on these Tahoes from '95 to '99. The only items you'll need for this is a new four wheel drive front axle shift actuator from 1aauto.com and an adjustable wrench.

Your front axle shift actuator is located right here and the harness for it is right here. Pull this off that bracket and pull back on this tab and pull the harness free. Then, pull the wire out of that bracket. Now, using an adjustable wrench, you just want to twist this out. Once you break it free, you can twist it the rest of the way out by hand and then it just pulls free.

On the left is the old front axle shift actuator. On the right is the new one from 1aauto. You can see they're identical and they're going to fit exactly the same. Take your new front axle shift actuator and twist it into place and then tighten it up with your adjustable wrench. Now, you want to put the wire back through that bracket and then reconnect the harness. Then, just slide the harness back onto that bracket and you're all set.

We hope this helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.

Tools needed for replacement:

    Pliers, Cutters & misc Wrenches

  • Adjustable Wrench

1988 - 1995  GMC  K3500 Truck
1988 - 1995  GMC  K1500 Truck
1988 - 1995  GMC  K2500 Truck
1988 - 1995  Chevrolet  K3500 Truck
1988 - 1995  Chevrolet  K1500 Truck
1988 - 1995  Chevrolet  K2500 Truck
1992 - 1994  Chevrolet  Blazer Full Size
1992 - 1995  GMC  Yukon
1995 - 1995  Chevrolet  Tahoe
1992 - 1995  Chevrolet  Suburban K1500
1992 - 1995  Chevrolet  Suburban K2500
1992 - 1995  GMC  Suburban K1500
1992 - 1995  GMC  Suburban K2500
1996 - 1996  Chevrolet  Tahoe
1996 - 1996  GMC  Yukon
1996 - 1996  Chevrolet  K1500 Truck
1996 - 1996  Chevrolet  K2500 Truck
1996 - 1996  Chevrolet  K3500 Truck
1996 - 1996  GMC  K1500 Truck
1996 - 1996  GMC  K2500 Truck
1996 - 1996  GMC  K3500 Truck
1996 - 1996  Chevrolet  Suburban K1500
1996 - 1996  Chevrolet  Suburban K2500
1996 - 1996  GMC  Suburban K1500
1996 - 1996  GMC  Suburban K2500
