How To Remove Rear Door Panel 2000-05 Buick LeSabre
Created on: 2011-06-10
How to remove or replace the interior door panel trim on your vehicle. You need to remove the door panel for a number of different repairs, for example door handles, window regulators, power window motors, door locks and more to the Buick LeSabre, years 00, 01, 02, 03, 04, and 05.
-
step 1 :Remove the Door Panel
- Pry out the door handle trim piece with a flat blade screwdriver
- Remove the Phillips screw in the door handle
- Pry out the door panel with a door panel clip tool or putty knife
- Lift the door panel up and off
- Disconnect the window switch wiring harness
-
step 2 :Installing the Door Panel
- Connect the window switch wiring harness
- Lift the door panel into place
- Push in the door panel clips
- Insert the Phillips screw in the door handle
- Push in the door handle trim piece
Tools needed
-
Flat Blade Screwdriver
Phillips Head Screwdriver
Putty Knife
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to remove and put back on a rear door panel on this 2003 Buick LeSabre. The only tools you'll need are a flat blade screwdriver, a Phillips screwdriver, and a putty knife or door panel clip tool.
Take a regular screwdriver and gently pry out, hands under, and pull that front panel right out. Use a little Phillips screwdriver right here and remove that screw. Now you're going to use a putty knife or a door panel clip tool, work it under, and pull quick and firm. It comes up and off. Then in behind here is a lead. The lead is clipped on here. I just unclipped it. Press down there. Take it off.
Reconnect this lead and get it clipped right up here. Now there's a metal strip along here. You need to make sure it clips into this channel up here and it's just a matter of pushing it against. Make sure your tabs go in. Very carefully put your screw in.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
