How to Remove Glove Box 2000-07 Volvo V70
Created on: 2018-11-30
How to replace a broken, damaged or burnt out glove box light bulb to the 00, 01, 02, 03, 04, 05, 06, 07 Volvo V70
-
step 1 :Removing the Glove Box
- Remove the two T25 Torx screws from the kick panel underneath the glove box
- Pull the kick panel down and out
- Open the glove box
- At the rear of the glove box, grab and pull the piston off of its tab
- At the rear of the glove box, pull the two ear tabs forward
- Lower the glove box
- Remove the three T25 Torx screws on either side and the two screws on top (8 total) from the trim
- Disconnect the glove box light electrical connector
- Disconnect the dome light electrical connector
- Remove the glove box
-
step 2 :Installing the Glove Box
- Connect the dome light electrical connector
- Connect the glove box light electrical connector
- Insert the glove box and trim to the dash
- Tighten the three T25 Torx screws on either side and the two screws on top (8 total) from the trim
- Press the glove box in quickly to lock in the ear tabs
- At the rear of the glove box, pull the piston up and connect it to its tab
- Close the glove box
- Insert the kick panel into place
- Tighten the two T25 Torx screws to the kick panel
