How To Install Rear Brake Pads 2000-07 Chevy Monte Carlo
Created on: 2014-07-28
How to repair, install, fix, change or replace your own worn, squeaky, fading old brakes on 00, 01, 02, 03, 04, 05, 06, 07 Chevy Monte Carlo.
-
step 1 :Removing the Wheel
- Loosen the 19mm lug nuts with the vehicle on the ground
- Raise the vehicle with a floor jack
- Secure the vehicle on jack stands
- Remove the lug nuts
- Pull off the wheel
-
step 2 :Removing the Brake Pads
- Remove top 14mm bolt from the brake caliper and loosen the bottom bolt
- Pull the caliper aside
- Pry the brake pads off with a flat blade screwdriver
- Remove the brake pad slides
-
step 3 :Installing the New Brake Pads
- Put an old pad in the caliper
- Use a large C-clamp and the old pad to push the pistons back
- Clean the slides with a wire brush
- Apply brake grease to the brake pads
- Install the new brake pads into the bracket
- Hammer the caliper on
- Tighten the 14mm bolts to the caliper
-
step 4 :Reattaching the Wheel
- Slide the wheel into place
- Start the lug nuts by hand
- Tighten the lug nuts preliminarily
- Lower the vehicle to the ground
- Tighten the lug nuts to 100 ft/lbs in a crossing or star pattern
- Reattach the center cap
- Tighten the lug nut covers with a 19mm socket
-
step 5 :Testing the Brakes
- Pump your brakes repeatedly until they feel firm
- Test your brakes at 5 miles per hour and then 10 miles per hour
- Road test the vehicle
Tools needed
-
14mm Wrench
Large C-Clamp
Hammer
Flat Blade Screwdriver
Torque Wrench
Jack Stands
19mm Socket
Ratchet
Wire Brush
Floor Jack
Brake Parts Cleaner
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks.
In this video, we're going to show you how to replace the rear brake pads on this 2003 Chevy Monte Carlo. We show you on the passenger's side but the driver's side is the same procedure. The items you'll need for this include new brake pads from 1AAuto.com, a 19mm socket and ratchet, a 14mm wrench, a flat blade screw driver, a hammer, a large C-clamp, a wire brush, brake grease, jack and jack stands, and a torque wrench.
Loosen up the lug nuts, pull your hub cap off, and then remove the lug nuts. You want to loosen these while the vehicle is on the ground, then raise the vehicle and remove them the rest of the way if you don't have air-powered tools. Now, just pull the wheel off.
Next, remove the top caliper bolt and loosen the bottom one. I use a 14mm wrench and hook it on with another wrench to get some extra leverage. Again, remove the top one and loosen the bottom one. Once you remove the top one, then you can pull the caliper back. Once you pull back the caliper, just pry out the brake pads with a flat blade screw driver. Then pry out these brake pad slides.
On the top are the new pads from 1A Auto; on the bottom are the old ones. You can see that the new ones from 1A Auto are exactly the same. Pull back your caliper and then use an old brake pad and push in that piston. Just twist the large C-clamp. It will push the brake pad against the piston and push the piston in. Clean off your brake pad slides using a wire brush, and then push them back into place. Then apply brake grease to the tabs on either end of your brake pads. Slide the brake pads into place and then push your caliper back up into place over the brake pads. Then replace those two 14mm bolts and tighten them up.
Replace your wheel, replace the lug nuts, and then tighten them preliminary. Lower the vehicle and tighten them the rest of the way. Then torque each of these to 100 foot-pounds in a crossing pattern. Replace your hub cap and tighten up these lug nut caps. Whenever you do any work on the brakes, you want to just pump the brake pedal until it firms out and try a stopping test from five miles per hour, then ten miles.
We hope this video helps you out. Brought to you by www.1AAuto.com, your source for quality replacement parts and the best service on the Internet. Please feel free to call us toll-free, 888-844-3393. We're the company that's here for you on the Internet and in person.
