How to Replace Outer Tie Rod 2003-05 Honda Civic
Created on: 2016-04-21
New Tie Rod from 1AAuto.com How to repair, install, fix, change or replace a broken, busted, bad, loose, or damaged outer tie rod on 03, 04, 05 Honda Civic
-
We recommend an alignment after completing this repair
step 1 :Removing the Wheel
- Loosen the 19mm lug nuts with the vehicle on the ground
- Raise the vehicle with a floor jack
- Secure the vehicle on jack stands
- Remove the lug nuts
- Pull off the wheel
-
step 2 :Removing the Outer Tie Rod
- Loosen the 24mm lock nut with a 21mm wrench and hammer
- Make note of how far you turn the inner tie rod to turn it back for reinstallation
- Remove the 24mm nut from the outer tie rod end
- Remove the cotter pin with needle nose pliers
- Remove the ball joint nut
- Strike the steering knuckle with a hammer to loosen the outer tie rod
- Twist off the outer tie rod by hand
-
step 3 :Installing the New Outer Tie Rod
- Twist the new outer tie rod onto the inner tie rod
- Push the outer tie rod into the steering knuckle
- Fasten the castle nut onto the outer tie rod
- Tighten the castle nut to 32 foot-pounds
- Push the cotter pin through the castle nut
- Twist the cotter pin into place with needle nose pliers
- Make sure the inner tie rod is in its correct position
- Hold the tie rod with an 18mm wrench
- Tighten the 24mm lock nut
-
step 4 :Reattaching the Wheel
- Slide the wheel into place
- Start the lug nuts by hand
- Tighten the 19mm lug nuts preliminarily
- Lower the vehicle to the ground
- Tighten the lug nuts to 80 foot-pounds in a crossing or star pattern
Tools needed
-
21mm wrench
24mm Wrench
Hammer
Torque Wrench
Rust Penetrant
17mm Socket
Ratchet
Needle nose pliers
1/2 Inch Breaker Bar
Brought to you by 1AAuto.com, your source for quality replacement parts and the best service on the Internet.
Hi, I'm Mike from 1A Auto. I hope this how-to video helps you out, and next time you need parts for your vehicle, think of 1AAuto.com. Thanks!
In this video, we're going to show you how to replace the outer tie rod. This is a 2003 Honda Civic. It's the same for the 2001 to 2005 Honda Civic, as well as a couple of other Honda models. We show you this on the driver side, but the passenger side is the same procedure. Items you'll need include a new outer tie rod or tie rods from 1AAuto.com, 17mm to 24mm sockets, wrenches and ratchet, a torque wrench, breaker bar or tire iron, small hammer, needle nose pliers, and some penetrating oil.
Remove the front wheel held on by 19mm lug nuts. If you have a different style hubcap, you'll need to remove that. Just use a breaker bar or your tire iron and loosen your lug nuts while the tire is on the ground. Raise and support the vehicle. Now, remove the rest of the lug nuts the rest of the way, and the wheel and tire.
The outer tie rod is right here; 17mm nuts hold it in here. Remove the cotter pin. Then there's a 21mm lock nut, which we're going to use a nice 21mm wrench. As you're looking at it, you're turning it clockwise. We're just going to turn that about a quarter of a turn. If, when you turn this lock nut, you also turn the inner tire rod, just make note of it so that you can turn it back for the same amount, just so that you can get yourself in a good preliminary alignment. You will want to have your vehicle aligned after you do this repair.
Remove the cotter pin. Normally, the pin should drive out easily, but it's giving us a hard time. We're going to use a little bit of penetrating oil. Let it sit for a bit. You may have to use a set of these cutting pliers. We really get half of the cotter pin off. A lot of times, if you've got it off and pretty well damaged, you can just pull the nut off and it will shear it right off as it comes off. Give the steering knuckle a few good taps with the hammer to break the tie rod free. Now, you can just take your tie rod right off.
Old part from the vehicle, new tie rod in from 1A Auto. You can see it's exactly the same. Take the castle nut off. New part comes with a new lock nut and a cotter pin. If you like, you can grab hold of your inner tie rod, free up your existing lock nut, and take it off. Not necessary though if you can put the new tie rod on and use the existing lock nut that's on there already. Put the tie rod in. It should go right around to about where it was.
Reinstall your tie rod. Put the castle nut on. Tighten the castle nut to 32-ft/lbs. Then tighten it any more you need to get the cotter pin through the hole in the tie rod. I can see the hole there. Probably need to go another 16th of a turn. Insert the cotter pin.
Use a pair of piers and bend it over. Appropriate size wrench to hold the tie rod; in this case, it's an 18mm. Then 24mm to get our lock nut on the back. Tighten it up.
Put your wheel back in place. Start your lug nuts. We'll tighten them preliminarily and then torque them when the vehicle is back down on the ground. Tighten your lug nuts 80-ft lbs and just cross in the pattern.
Thanks for tuning in. We hope this video helped you out. Next time you need parts for your car, please visit 1AAuto.com. Also check out our other helpful how-to and diagnosis videos.
